C&K COMPONENTS Y97BT21A5HAFP Micro Snap-Acting Switch
The C&K Components MDS series micro snap-acting detect switches are designed for applications requiring a compact and reliable switching solution. These switches offer a snap-acting tactile feel, a small package size, and are available in both vertical and right-angle PCB mount configurations. They are RoHS compliant and suitable for use in medical devices, consumer electronics, and ATCA applications. The switches feature a copper alloy construction with silver-plated contacts, ensuring reliable electrical contact. Various termination styles are available to suit different assembly requirements, including PC thru-hole and SMT options with different bracket configurations.
C&K COMPONENTS Y97BT21A5HAFP Micro Snap-Acting Switch Specifications:
- Contact Rating: 300mA @ 30 VDC
- Mechanical & Electrical Life: 30,000 operations
- Contact Resistance: 100 m Ω max. inital
- Operating Temperature: -25ºC to +70ºC
- Solderability: According to lead free solder profiles
- Operating Force: 50g Max
- Release Force: 3g Min
- Base Material: PA9T
- Cover & Actuator Material: PA9T
- Movable Contact Material: Copper alloy, silver plated
- Stationary Contacts Material: Copper alloy, silver plated
- Terminals Material: Copper alloy, silver plated
Buy the Y97BT21A5HAFP C&K COMPONENTS Micro Snap-Acting Switch | myMectronic
Purchase the C&K Components Y97BT21A5HAFP Micro Snap-Acting Detect Switch securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy C&K COMPONENTS Y97BT21A5HAFP?
You can click on the BUY or RFQ button to purchase Y97BT21A5HAFP from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part Y97BT21A5HAFP?
You can download the Y97BT21A5HAFP datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of Y97BT21A5HAFP?
C&K COMPONENTS
