FINDER 202290244000 Industrial Control Relay
This DIN rail mounting dual-pole relay features a 24 V DC coil voltage and a DPDT normally open contact configuration, capable of switching up to 16 amps. Its compact design integrates seamlessly into control panels, offering reliable switching performance with cadmium-free contacts. Suitable for automation and industrial control systems, it provides durability with a mechanical life of 300,000 cycles and an electrical life of 100,000 cycles at rated load. The relay has an insulation withstand voltage of 3,500 V AC and a dielectric strength of 2,000 V AC between open contacts, ensuring safe operation in critical applications.
FINDER 202290244000 Industrial Control Relay Specifications:
- Coil Voltage: 24 V DC
- Contact Configuration: Double pole double throw (DPDT), normally open
- Rated Current: 16 A
- Maximum Peak Current: 30 A
- Switching Voltage: AC 250/400 V
- Rated Load AC1: 4000 VA
- Rated Load AC15: 750 VA
- Mechanical Life: 300,000 cycles
- Electrical Life: 100,000 cycles
- Insulation Voltage: 3,500 V AC
- Dielectric Strength Between Contacts: 2,000 V AC
- Operating Temperature Range: -40°C to +60°C
- Protection Class: IP 20
Buy the Buy Industrial Relay Part Number 202290244000 Online
Secure your industrial automation projects by ordering the high-quality control relay with Part Number 202290244000 online. Its robust design features a 24 V DC coil, 16 A switching capacity, and cadmium-free contacts, ensuring long-lasting, dependable performance in demanding environments. Ideal for panel mounting, this relay offers high dielectric strength and high insulation voltage, suitable for various automation applications. Purchase today to benefit from fast delivery and a product that guarantees safe, efficient, and durable operation in your control systems.
Order your industrial relay with Part Number 202290244000 today and enhance your control systems with reliable, high-capacity switching.
Frequently Asked Questions
Where can I buy FINDER 202290244000?
You can click on the BUY or RFQ button to purchase 202290244000 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 202290244000?
You can download the 202290244000 datasheet or visit the FINDER website for support.
Who is the manufacturer of 202290244000?
FINDER
