Finder 415280240000 Industrial Relay System
The product is a versatile relay system suitable for various industrial and automation applications. It features multiple configurations including single-pole and multi-pole designs with contact ratings up to 16A at 250V AC and 12A at 250V DC. The relays provide high dielectric strength, environmental protection, and robust insulation between coil and contacts. Suitable for PCB mounting with options for screw terminal sockets and PCB sockets, these relays are rated for different voltage ranges. Ideal for controlling motors, switching loads, and automation systems, they offer long electrical life, fast operation, and superior reliability in demanding environments.
Finder 415280240000 Industrial Relay System Specifications:
- Contact configuration: 1 CO (SPDT), 2 CO (DPDT)
- Rated current: up to 16A at 250V AC, 12A at 250V DC
- Rated voltage: 110V to 250V AC, 24V to 110V DC
- Dielectric strength: 6 kV between coil and contacts
- Environmental protection: IP20, RTI compliant, operating temperature -40°C to +85°C
- Coil voltage options: 6V, 12V, 24V, 48V, 60V, 110V AC/DC, 230V AC/DC
- Mechanical life: 10^7 cycles, electrical life at rated load: 10^5 cycles
- Ignition and release times: 8 to 10 ms, insulation between contact sets: reinforced
- Suitable for PCB and socket mounting, with options for screwless and screw terminal sockets
- Compliance with UL, VDE, and other approval standards
- Rated load for AC1: up to 3000 VA, rated load for AC15: up to 750 VA
Buy the Finder Series Industrial Relay: 415280240000
Order the Finder 415280240000 industrial relay online today to benefit from high current ratings, durable construction, and versatile configurations. Perfect for controlling motors, switching loads, and automation applications, this relay provides fast response times, long electrical life, and excellent insulation properties. Whether for PCB or socket mounting, it offers a reliable solution for demanding industrial environments. Purchase online now for quick delivery, competitive prices, and technical support to ensure seamless integration into your systems.
Buy Finder 415280240000 now and experience unmatched reliability and performance for load switching and automation needs.
