Hammond Manufacturing 1455JALBK10 Aluminum Enclosure
The 1455JALBK10 is a durable extruded aluminum enclosure within the 1455 series, featuring a black anodized finish. Designed for housing PC boards or equipment interfacing, it includes removable belly plates, metal end panels, and options for plastic end caps. Constructed with a minimum 1.5 mm thickness aluminum body, it offers easy installation with internal slots for mounting PC boards horizontally, plus rubber feet for stability. Suitable for electronic projects requiring rugged, customizable enclosures with various accessory options and anodized color finishes.
Hammond Manufacturing 1455JALBK10 Aluminum Enclosure Specifications:
- Material: Extruded aluminum with a minimum thickness of 1.5 mm
- Finish Options: Clear, black, blue, red anodized
- Dimensions: Length 80 mm, Width 45 mm, Depth 25 mm
- Design: Includes slide removable belly plate (except sizes A-D)
- Mounting: Internal slots for horizontal PC board installation
- Hardware: #6 x 3/8” steel screws, thread rolled, zinc plated
- Screw Torque: 5 Ibf-in recommended
- Accessories: Rubber feet, plastic or metal end plates, bezels
- Construction: Rugged extruded aluminum body for durability and heat dissipation
- Application: Suitable for electronic equipment housing and interfacing components
Buy the Hammond Series 1455 Aluminum Enclosure: 1455JALBK10
Order the Hammond 1455JALBK10 aluminum enclosure online today to protect your electronic components effectively. Featuring durable extruded aluminum with a black anodized finish, this rugged enclosure offers easy mounting with internal slots and includes removable belly plates. Its versatile design supports PC boards and interfacing equipment, making it ideal for industrial automation, control panels, and electronic housing needs. With accessory options like end plates, bezels, and rubber feet, this enclosure guarantees durability, customization, and reliable performance for your electronic applications.
Buy Hammond 1455JALBK10 aluminum enclosure now and experience unmatched durability, flexible customization, and reliable protection for your electronic projects.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 1455JALBK10?
You can click on the BUY or RFQ button to purchase 1455JALBK10 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 1455JALBK10?
You can download the 1455JALBK10 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 1455JALBK10?
Hammond Manufacturing
