Hammond Manufacturing 162D20 Power Transformer
This compact, industrial-grade power transformer is designed for low-voltage PCB mounting, offering multiple output voltages from 5V to 36V. It features dual winding secondaries, a split bobbin low-profile design, and options for single or dual primary voltages of 115V or 115/230V. The transformer supports 50/60 Hz operation, has high insulation with a 2,500V RMS Hipot rating, and is suitable for various industrial applications requiring reliable power management with exceptional electrical performance and easy PCB integration. Its robust construction ensures long-lasting durability and efficient performance in demanding environments.
Hammond Manufacturing 162D20 Power Transformer Specifications:
- Operating frequency: 50/60 Hz
- Primary voltages: 115V single or 115/230V dual primary options
- Secondary voltages range: 5V to 48V RMS, various models and power ratings
- Power ratings: from 1.1VA to 36VA models available
- Insulation: Class B, Hipot 2,500V RMS
- Construction: Low profile split bobbin design with dual winding secondaries
- Mounting: Four-hole mounting on larger sizes, no hardware on smaller models
- Dimensions vary by model, typical length from 1.38 to 2.63 inches, height up to 1.56 inches
- Enclosure Material: Thermoplastic or equivalent for durability
- Weight varies from approximately 0.17 to 1.1 pounds depending on the size
- Certification: UL/US recognized, RoHS compliant
Buy the Hammond Series Low Voltage PCB Mount Transformer: 162D20
Purchase the Hammond 162D20 power transformer online today and benefit from industry-leading reliability and efficiency. Engineered for low-voltage PCB mounting, this transformer offers multiple output voltages ideal for industrial applications. Its compact design, high insulation, and dual primary options ensure flexible integration into your power management systems. Whether you need a 5V or 36V output, this transformer provides consistent, safe, and durable power conversion. Order now to enhance your electrical projects with proven quality and support for demanding environments.
Get Hammond 162D20 today—built for precision and long-lasting durability in industrial power management.
