Hammond Manufacturing 260E Power Transformer
This power transformer is designed for versatile industrial applications, delivering reliable voltage conversion for preamps, low power amps, and test equipment. Featuring universal primary taps for 100, 120, 220, or 240 VAC at 50/60 Hz, it includes a Faraday shield between windings to minimize capacitive coupling and electromagnetic interference. The open frame, chassis-mount construction ensures easy installation, with grounding of the shield to reduce high-frequency noise. It offers two secondary outputs, 5V@2A and 6.3V@3A, along with robust leads for secure connections. Suitable for various power management needs in manufacturing or maintenance settings, providing consistent and efficient performance.
Hammond Manufacturing 260E Power Transformer Specifications:
- Primary Voltage: 100, 120, 220, 240 VAC, 50/60 Hz
- Secondary #1: 5V@2A, 6.3V@2A
- Faraday shield between primary and secondary windings
- Lead Length: Minimum 5 inches
- Mounting: Chassis mount, two-hole or four-hole options
- Dimensions: Approximately 4.03 x 2.65 x 2.62 inches
- Material: Open frame construction with grounding shield
- Maximum VA: 80 VA
- Designed for power supply and testing purposes
- Includes grounding leads and thermal management features
Buy the Hammond 260E – Reliable Power Transformer for Industrial Applications
Purchase the Hammond 260E power transformer online today for dependable voltage regulation and power management in industrial settings. Its universal primary taps accommodate various input voltages, while the Faraday shield minimizes noise and interference. Designed for easy mounting with two or four-hole options, it features dual secondary outputs, robust leads, and efficient thermal performance. Whether for preamp applications, low power amps, or test equipment, this transformer offers consistent, high-quality electrical performance. Order online now and enhance your power supply system with trusted Hammond reliability.
Get Hammond 260E today—built for reliable voltage conversion, efficient performance, and easy installation in manufacturing or test environments.
