Hammond Manufacturing RMCV9058BK1 Rack Chassis
The RMCV9058BK1 is an economical 3U rack chassis with vented top and bottom panels, made of durable aluminum with a satin texture and black powder coat. Designed for applications needing frequent assembly, it features all-machine screw and PEM nut construction for easy maintenance. The chassis includes top, bottom, side, front, and rear panels, plus rubber self-adhesive feet and rack mount brackets. Its lightweight design ensures portability in industrial environments. Internal access is straightforward—only four screws remove for internal maintenance, making it ideal for modular electronic systems and manufacturing setups.
Hammond Manufacturing RMCV9058BK1 Rack Chassis Specifications:
- Material: Aluminum with satin texture powder coat finish
- Color: Black
- Number of Rack Units: 3U
- Overall Dimensions: 17.00 inches width x 13.00 inches depth
- Panel Thickness: Side panels 0.125 inch, front/rear 0.064 inch, top/bottom 0.062 inch
- Weight: Light, suitable for industrial use
- Construction: All-machine screw & PEM nut
- Vented panels: Top and bottom for airflow
- Includes: Panels, rubber self-adhesive feet, rack mount brackets, hardware
- Access: Remove only four screws from any panel for interior access
- Mounting: Can be used with or without rack mounting ears
- Finish: Rugged satin texture black powder paint
- RoHS Compliant
- Manufactured in North America
Buy the Hammond Series Rack Chassis: RMCV9058BK1
Order the Hammond RMCV9058BK1 online today to benefit from high-quality, durable aluminum construction, easy internal access with minimal screws, and versatile mounting options. Designed for efficient assembly and disassembly in industrial and professional environments, this 3U vented chassis offers excellent airflow and a rugged finish. Its lightweight build makes it easy to handle, while comprehensive hardware ensures straightforward installation. Take advantage of quick shipping and secure online purchase to enhance your electronic or manufacturing projects with this reliable enclosure.
Buy Hammond RMCV9058BK1 now and experience unmatched reliability and performance in modular rack solutions for industrial and professional applications.
