Honeywell FSS005WNGB Low Profile Force Sensor
Honeywell's Low Profile Force Sensor series offers precise force measurement in a compact design, suitable for medical and industrial applications. Featuring a piezoresistive silicon sensing element, the sensors provide stable, low-noise output with a high cycle-to-failure rate of 20 million MCTF at 25°C. They support automated PCB assembly via Surface Mount Technology, reducing manufacturing costs. Capable of handling forces up to 20 N with low deflection of approximately 30 µm, these sensors are resistant to electrostatic discharge and temperature variations, ensuring reliable performance in demanding environments.
Honeywell FSS005WNGB Low Profile Force Sensor Specifications:
- Force sensing range: 0 to 20 N
- Excitation voltage: 3.3V to 6V DC
- Null offset: -30 mV to +30 mV
- Span: 330 to 390 mV
- Linearity: ±40.5% span
- Sensitivity: 2.2 to 7.8 mV/V/N
- Sensitivity shift: ±5% over temperature
- Repeatability: ±0.2% span
- Response time: 0.1 to 0.5 ms
- Input resistance: 4.0 to 6.0 kΩ
- Output resistance: 4.0 to 6.0 kΩ
- Recommended force range: up to 20 N
- Operating temperature: -40°C to 85°C
- Shock resistance: 150 g
- Vibration resistance: 0 to 2 kHz, 20 g
- Mean Cycles To Failure: 20 million at 25°C
- Material: Stainless steel ball, Silicon sensing element
- RoHS compliant, Electrostatic discharge resistance: Level 3B (8 KV)
Buy the Honeywell Series FSS Low Profile Force Sensor: FSS005WNGB
Experience reliable and accurate force measurement with Honeywell's Low Profile Force Sensor. Designed for compact spaces, it features high durability, stable output, and compatibility with automated PCB assembly. Suitable for both medical and industrial applications, it provides excellent resistance to ESD, temperature fluctuations, and mechanical stress. Easy to integrate into your system, this sensor ensures long-lasting performance, reducing maintenance costs. Acquire Honeywell FSS005WNGB online today for high-quality, dependable force sensing in your project.
Get Honeywell FSS005WNGB today—built for precise force measurement in compact and reliable design.
Frequently Asked Questions
Where can I buy Honeywell FSS005WNGB?
You can click on the BUY or RFQ button to purchase FSS005WNGB from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part FSS005WNGB?
You can download the FSS005WNGB datasheet or visit the Honeywell website for support.
Who is the manufacturer of FSS005WNGB?
Honeywell
