ITT CANNON DAU15SA197F0 Industrial D-Sub Connector
The DAU15SA197F0 is a 15-position through-hole D-sub connector housing constructed from steel with a durable gold-over-nickel finish on copper alloy stamped contacts. The black insulator is made from UL94V-0 rated glass-filled thermoplastic, ensuring safety and high-performance in industrial environments. Designed to accommodate wire gauges from AWG 18 to 30, it supports up to 50, 200, or 500 mating cycles. The connector features a maximum current rating of 5A, rated dielectric withstand voltage of 1000 VAC, and operates within a temperature range of -55°C to +125°C, suitable for demanding industrial use.
ITT CANNON DAU15SA197F0 Industrial D-Sub Connector Specifications:
- Wire Gauge Range: AWG 18-30
- Mating Cycles: 50, 200, 500
- Dielectric Withstanding Voltage: 1000 VAC at sea level
- Current Rating: 5 A maximum
- Contact Resistance: 15 milli Ohm max
- Operating Temperature: -55°C to +125°C
- Shell Material: Steel with tin/nickel finish
- Insulator Material: Glass-filled thermoplastic, UL 94V-0 rated
- Insulator Color: Black
- Contact Arrangement: 15 contacts, size 20
- Gender: Socket
- Contact Type: Stamped
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Termination: Crimp
- Mounting Method: 120-inch (3.05mm) through hole
Buy the Cannon Series D*U D-Sub Connector: DAU15SA197F0
Enhance your projects with the reliable Cannon Series D*U D-Sub connector. Crafted from steel with gold-plated copper alloy contacts, it offers excellent durability, electrical performance, and high-temperature tolerance. The black thermoplastic insulator rated UL94V-0 ensures safety and flame resistance. Designed for industrial environments, it supports wire gauge ranges of AWG 18-30, rated for 5A current, and withstands up to 50, 200, or 500 mating cycles. Perfect for high-performance electrical connections in demanding applications.
Order your Cannon Series D*U D-Sub connector DAU15SA197F0 today and ensure reliable performance for your industrial applications with durable steel housing and gold-plated contacts.
Frequently Asked Questions
Where can I buy ITT CANNON DAU15SA197F0?
You can click on the BUY or RFQ button to purchase DAU15SA197F0 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DAU15SA197F0?
You can visit the ITT CANNON website for support.
Who is the manufacturer of DAU15SA197F0?
ITT CANNON
