JST 32FLTSM2GBTBLFSN Surface-Mount Terminal Block
This JST FLT Series 32-position surface-mount terminal block with a 0.5mm pitch provides reliable electrical connections in compact electronic assemblies. Featuring a zero insertion force mechanism, heat-resistant design suitable for surface mounting, and in-line surface mount tails, it supports FFC and FPC with a conductor pitch of 0.5mm and width of 0.35mm. Rated for 0.5A at 50V, with a temperature range from -25°C to +85°C, this connector complies with RoHS standards and offers durable, environmentally resistant performance in tight spaces.
JST 32FLTSM2GBTBLFSN Surface-Mount Terminal Block Specifications:
- Current rating: 0.5A AC, DC
- Voltage rating: 50V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/40mΩ max, after environmental testing/60mΩ max
- Insulation resistance: 800MΩ min
- Withstanding voltage: 200V AC/minute
- Applicable FFC and FPC: Conductor pitch/0.5mm, width/0.35mm, thickness/0.3±0.03mm
- Material: Phosphor bronze contacts, tin-plated; PA 6T housings UL94V-0
- RoHS compliant
- Designed for surface mounting with embossing tape for automatic placement
Buy the JST Series FLT 0.5mm Connector: 32FLTSM2GBTBLFSN
Purchase your JST Series FLT 32FLTSM2GBTBLFSN connector today online and enhance your electronic assembly's reliability. This high-quality, compact connector with a 0.5mm pitch supports FFC and FPC applications, offering excellent resistance to environmental factors. Its RoHS compliance and robust construction make it ideal for space-constrained projects requiring durable and reliable electrical connections. Enjoy quick, easy ordering and fast delivery to keep your manufacturing process on schedule and meet your project specifications effortlessly.
Order your JST Series FLT 32FLTSM2GBTBLFSN today and ensure reliable, space-saving electrical connections for your electronic projects.
