JST B02BPSIRC1LFSN Connector Header
This 2-position connector header from the PSI series features a 4.00mm pitch and is designed for through-hole mounting. It supports wire gauges from 26 to 16 AWG and includes tin-plated copper alloy contacts for reliable electrical performance. The connector offers a C keying option to prevent incorrect mating and is color-coded red for quick visual identification. Its glass-filled PBT housing with UL94V-0 flame resistance ensures durability and safety in various applications, including automation, control systems, and electronic equipment requiring secure, high-current connections.
JST B02BPSIRC1LFSN Connector Header Specifications:
- Pitch: 4.00mm
- Number of Circuits: 2
- Wire Range: AWG 26 to 16
- Contact Material: Copper alloy, tin-plated
- Housing Material: Glass-filled PBT, UL94V-0
- Color: Red
- Flammability: UL 94V-0
- Rated Voltage: 300 V AC/DC
- Temperature Range: -25°C to +85°C
- Contact Resistance: Initial/ 10 mΩ max., After environmental tests/ 20 mΩ max.
- Insulation Resistance: ≥ 1,000 MΩ
- Withstanding Voltage: 1,500 VAC/minute
- RoHS Compliant
Buy the Buy JST PSI Connector Part Number B02BPSIRC1LFSN Online
Purchase the JST PSI series connector header with 4.00mm pitch online today. Designed for secure through-hole mounting, supporting wire gauges from 26 to 16 AWG, it features tin-plated contacts and a C keying option to prevent mis-mating. Its durable glass-filled PBT housing with UL94V-0 flame resistance ensures safety and longevity in your electronic and automation applications. Ideal for high-current connections, this connector offers reliable performance, easy installation, and visual identification through its red color, making it a valuable component for various manufacturing and control systems.
Order your JST PSI series 2-position connector header with 4.00mm pitch today and ensure reliable, high-quality connections for your electronic projects.
