JST B02BPSIYB1LFSN Connector Header
This is a 2-position connector header from the PSI Series with a 4.00mm pitch. It features through-hole mounting, is tin-plated for corrosion resistance, and includes B keying. The connector is suitable for connecting wires ranging from 16 to 26 AWG and has a yellow color coding for easy identification. Designed for reliable wire-to-board connections, it ensures secure locking and mis-mating prevention. Ideal for electronic applications requiring precise and durable connectors with high current capacity and robust insulation.
JST B02BPSIYB1LFSN Connector Header Specifications:
- Pitch: 4.00mm
- Number of positions: 2
- Mounting Type: Through-hole
- Contact Material: Copper alloy, tin-plated
- Current Rating: 12 A AC/DC
- Voltage Rating: 300 V AC/DC
- Temperature Range: -25°C to +85°C
- Wire Range: AWG #26 to #16
- Insulation Resistance: 1,000 MΩ min.
- Withstanding Voltage: 1,500 VAC/minute
- Colors: Yellow
- RoHS compliant
Buy the JST Series PSI Connector Header: B02BPSIYB1LFSN
Purchase the JST PSI connector header B02BPSIYB1LFSN online today. Designed for high durability, this 4mm pitch connector features B keying, tin-plated contacts, and supports wires from 16 to 26 AWG. Its through-hole mounting ensures secure attachment, while the yellow color coding simplifies identification. Ideal for electronic device assembly, it offers excellent electrical performance, high current capacity, and reliable insulation. Order now for fast delivery and ensure your project benefits from high-quality, corrosion-resistant connections that withstand demanding environments.
Get JST PSI connector header B02BPSIYB1LFSN today—built for reliable wire-to-board connections with secure locking and corrosion resistance.
Frequently Asked Questions
Where can I buy JST B02BPSIYB1LFSN?
You can click on the BUY or RFQ button to purchase B02BPSIYB1LFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B02BPSIYB1LFSN?
You can download the B02BPSIYB1LFSN datasheet or visit the JST website for support.
Who is the manufacturer of B02BPSIYB1LFSN?
JST
