JST B2P3VHBLLFSN Locking Header
This two-position, single-row, through-hole locking header features a 7.92 mm pitch and is designed for secure and reliable electrical connections in through-hole mounting applications. Made from copper alloy with tin-plated reflow treatment, it complies with RoHS standards and offers excellent electrical performance with low contact resistance and withstands voltages up to 1500V AC. Suitable for various electronic devices and applications requiring durable and stable connectivity, it provides a compact size, robust locking mechanism, and compatibility with standard PCB boards for efficient assembly and maintenance.
JST B2P3VHBLLFSN Locking Header Specifications:
- Pitch: 7.92 mm
- Contact Material: Copper alloy, tin-plated (reflow treatment)
- Temperature Range: -25°C to +85°C
- Voltage Rating: 1500V AC/minute
- Current Rating: 10A AC/DC (AWG #16)
- Applicable Wire: AWG #22 to #16
- Insulation Resistance: 1,000MΩ minimum
- Contact Resistance: Initial 10mΩ max, after testing 20mΩ max
- Applicable PCB Thickness: 1.6mm
- RoHS Compliance
- Dimensions: Length 7.92 mm, Width 11.82 mm, Height 3.96 mm
- Housing Material: PBT or Glass-filled PET, UL94V-0, natural (white)
- Mounting: Through-hole
- Model No.: B2P3VHBLLFSN
Buy the Buy JST Locking Header Part Number B2P3VHBLLFSN Online
Purchase the JST Locking Header B2P3VHBLLFSN online today for secure and stable electrical connections in your electronic projects. This 7.92 mm pitch locking header features corrosion-resistant copper alloy contacts with tin plating, ensuring high contact reliability and voltage withstand capacity up to 1500V AC. Its compact design suits through-hole PCB mounting, providing ease of installation and maintenance. RoHS compliant, it meets stringent environmental standards. Ideal for applications requiring dependable power and signal connectivity in consumer electronics, industrial machinery, and automation systems.
Get JST B2P3VHBLLFSN today—built for reliable connections and long-lasting durability in electronic assemblies.
Frequently Asked Questions
Where can I buy JST B2P3VHBLLFSN?
You can click on the BUY or RFQ button to purchase B2P3VHBLLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B2P3VHBLLFSN?
You can download the B2P3VHBLLFSN datasheet or visit the JST website for support.
Who is the manufacturer of B2P3VHBLLFSN?
JST
