JST HRP04S Four-Position Connector Receptacle
This 4-position connector receptacle from the HR Series is designed with a 2.5mm pitch for reliable, fast crimp-style connections. The component features a natural finish, suitable for various electronic assembly needs. It supports wire ranges from AWG 26 to 22 and is compliant with RoHS standards. The connector is constructed from phosphor bronze, tin-plated for corrosion resistance, and can handle currents up to 3A at 250V. Its slim, high-reliability design meets industry standards for easy installation in compact electronic devices, making it ideal for wire-to-board connections and modular systems.
JST HRP04S Four-Position Connector Receptacle Specifications:
- Current rating: 3A AC, DC (AWG #22)
- Voltage rating: 250V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/10mΩ max, after environmental testing/20mΩ max
- Insulation resistance: ≥ 1,000MΩ
- Withstanding voltage: 1,000V AC/minute
- Applicable wire: AWG #26 to #22
- Applicable PC board thickness: 0.8 to 1.6mm
- Material: Phosphor bronze, tin-plated, reflow treatment
- Connector type: Free hanging, crimp style
- Finish: Natural
- RoHS compliant
- Pitch: 2.5mm
- Number of positions: 4
Buy the Buy JST HR Series Connector Part Number HRP04S Online
Enhance your electronic projects with this high-quality four-position connector from the HR Series. Featuring a 2.5mm pitch and crimp-style design, it ensures quick and secure connections. Made from phosphor bronze with tin plating, it is RoHS compliant and supports AWG 26 to 22 wires. Its slim profile and reliable performance make it ideal for PCB-mounted components, wire-to-board applications, and modular assemblies. Purchase online today for a durable, industry-standard connection solution tailored for modern electronics.
Get JST HR Series connector HRP04S today—designed for reliable electrical connections in compact electronic systems.
Frequently Asked Questions
Where can I buy JST HRP04S?
You can click on the BUY or RFQ button to purchase HRP04S from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part HRP04S?
You can download the HRP04S datasheet or visit the JST website for support.
Who is the manufacturer of HRP04S?
JST
