JST LJ5F91GFM65 High-Current Connector
This JFA series high-current connector receptacle contact supports 8 AWG wire with an 11.0 mm contact length, ensuring reliable connections. Designed for easy mating, it features nickel-undercoated copper alloy contacts with selective gold-plating, complying with RoHS standards. Suitable for applications requiring robust electrical performance, it withstands voltage up to 3.0kV AC/minute and operates within -55°C to +105°C temperature range. The connector's modular design allows flexible configurations for high-current wiring needs, making it ideal for industrial and electronic equipment requiring durable, high-capacity connections.
JST LJ5F91GFM65 High-Current Connector Specifications:
- Current rating: Refer to matrix table for specific circuits
- Voltage rating: 3000V AC/minute
- Temperature range: -55°C to +105°C
- Withstanding voltage: 3.0kV AC/minute
- Applicable wire: AWG #16 to #8 (1.25 to 8.0mm2)
- Contact Material: Copper alloy, nickel-undercoated, gold-plated
- Contact length: 11.0 mm
- Flammability: UL94V-0
- Material: Glass-filled PBT, black, RoHS compliant
- Dimensions: Contact length 11.0 mm, overall width varies, supports modular configurations
- Compatible with crimping and hand tools for wiring
- Series: JFA J5000 series, high current capacity connector
- Standards: RoHS compliant, UL94V-0 flammability
Buy the Buy JST JFA Connector Series J5000 Part Number LJ5F91GFM65 Online
Purchase the high-current JST JFA Series J5000 connector LJ5F91GFM65 online today. Designed for robust performance, it supports 8 AWG wire with an 11.0 mm contact length. Its nickel and gold finishes ensure durability and reliable electrical contact. This connector is ideal for industrial, electronic, and high-current equipment, offering easy mating, RoHS compliance, and withstands voltage up to 3.0kV. Order now to secure dependable, high-quality connections for your projects with just a few clicks.
Order your JST JFA Series J5000 high-current connector LJ5F91GFM65 today and ensure reliable, high-capacity electrical connections for your projects.
