JST S14BPADSS1LFSN Connector Header
This 14-position connector header from the PAD series offers reliable performance for electronic assemblies. With a 2.00mm pitch, it supports a maximum voltage of 250V AC/DC and a current rating of 3A. The connector features a right-angle, top entry, shrouded design with four walls for enhanced protection and secure locking. Made from high-quality copper alloy and UL94V-0 rated materials, it includes a locking ramp for secure mating. Suitable for through-hole soldering on PCBs with a maximum thickness of 1.6mm, it complies with RoHS standards, ensuring eco-friendly manufacturing. Ideal for compact, high-density electronic systems requiring stable connections.
JST S14BPADSS1LFSN Connector Header Specifications:
- Current rating: 3A AC/DC
- Voltage rating: 250V AC/DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial/10mΩ; after environmental testing/20mΩ maximum
- Insulation resistance: 1,000MΩ minimum
- Withstanding voltage: 800V AC/minute
- Applicable wire: AWG #28 to #22
- Applicable PCB thickness: 1.6mm
- Material: Copper alloy, tin-plated
- UL94V-0 flammability rated
- RoHS compliant
- Connector type: Top entry, right-angle, shrouded with four walls
- Mounting style: Through-hole soldering
- Color: Natural
- Locking mechanism: Locking ramp for secure connection
Buy the JST Series PAD Connector: S14BPADSS1LFSN 250V 14-Position Connector Header
Discover the reliable JST connector header from the PAD series, featuring a 2.00mm pitch, rated for 250V and 3A. Its right-angle, top entry, shrouded design with four walls ensures secure and stable PCB connections. Made from high-quality, UL94V-0 rated materials, it includes a locking ramp for added security during mating. Suitable for through-hole soldering, it supports wire sizes from AWG #28 to #22 and is RoHS compliant, making it ideal for compact electronic systems requiring durable, high-performance connectors.
Buy JST S14BPADSS1LFSN now and experience unmatched reliability and performance in high-density electronic connections.
Frequently Asked Questions
Where can I buy JST S14BPADSS1LFSN?
You can click on the BUY or RFQ button to purchase S14BPADSS1LFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part S14BPADSS1LFSN?
You can download the S14BPADSS1LFSN datasheet or visit the JST website for support.
Who is the manufacturer of S14BPADSS1LFSN?
JST
