KEMET A750KS158M0JAAE014 Polymer Aluminum Capacitor
The KEMET A750 series polymer aluminum capacitor offers a high capacitance of 1,500 uF with a 20% tolerance, rated for 6.3 VDC and surge up to 7.2 VDC. Designed for a broad temperature range from -55°C to +105°C, it features lead wires with a 3.5mm spacing, compact dimensions of 8mm diameter and 12mm length, and robust reliability. RoHS compliant and halogen-free, this capacitor is suitable for various electronic applications requiring stability, low ESR, and long life performance in demanding environments.
KEMET A750KS158M0JAAE014 Polymer Aluminum Capacitor Specifications:
- Capacitance: 1500 uF
- Capacitance Tolerance: 20%
- Voltage DC: 6.3 VDC, surge up to 7.2 VDC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Dimensions: Diameter 8mm ±0.5mm, Length 12mm ±1mm, Lead Spacing 3.5mm ±0.5mm
- Lead Type: Wire leads
- RoHS Compliant: Yes
- Halogen Free: Yes
- Lifespan: 2000 hours at 105°C with capacitance within +/-20% of initial value
- Dissipation Factor: 12% at 120Hz 20°C
- Resistance: 14 mΩ at 100kHz 20°C
- Ripple Current: 4100 mA at 100kHz 105°C
- Leakage Current: 1890 μA at 20°C for 2 minutes
Buy the Buy KEMET Polymer Aluminum Part Number A750KS158M0JAAE014 Online
Discover the KEMET Polymer Aluminum Capacitor with 1500 uF capacity, rated for 6.3 VDC, suitable for demanding applications requiring high stability and reliability. This compact component operates across a wide temperature range from -55°C to +105°C and features lead wires with a 3.5mm spacing for easy mounting. RoHS compliant and halogen-free, it offers long life, low ESR, and excellent ripple current capacity, making it ideal for power supply filtering, energy storage, and automation systems. Purchase online today for fast delivery and proven performance.
Order your KEMET SeriesA750 A750KS158M0JAAE014 capacitor today and enhance your electronic projects with reliable, high-capacity power stabilization.
