KEMET A759MS566M1KAAE045 Polymer Aluminum Capacitor
The KEMET A759MS566M1KAAE045 polymer aluminum capacitor is designed for a wide range of industrial applications, including power supplies, DC-DC converters, and energy storage systems. Its polymer dielectric provides high capacitance density, low ESR, and excellent frequency characteristics. The capacitor's robust construction ensures long-term reliability and stability, even under demanding operating conditions. With a voltage rating of 80VDC and an operating temperature range of -55°C to +125°C, this capacitor is suitable for use in harsh environments. It is RoHS compliant and halogen-free, meeting stringent environmental standards.
KEMET A759MS566M1KAAE045 Polymer Aluminum Capacitor Specifications:
- Series: A759
- Dielectric: Polymer Aluminum
- Description: Single Ended, Polymer Aluminum
- Capacitance: 56 uF
- Capacitance Tolerance: 20%
- Voltage DC: 80 VDC, 92 VDC (Surge)
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Life: 2000 Hrs (+/-20% Initial Capacitance, 1.5x DF MAX, Leakage Within Limit)
- Dissipation Factor: 12% 120Hz 20C
- Resistance: 45 mOhms (100kHz 20C)
- Ripple Current: 2630 mAmps (100kHz 105C), 1520 mAmps(100kHz 125C)
- Leakage Current: 672 uA (2min 20°C)
- D: 10mm +/-0.5mm
- L: 12mm +/-1mm
- S: 5mm +/-0.5mm
- LL Negative: 15mm MIN
- LL Positive: 19mm MIN
- F: 0.6mm +/-0.05mm
- Packaging: Bulk, Bag
- Packaging Quantity: 250
