KEMET ALC70A103EH100 Electrolytic Capacitor
The aluminum electrolytic capacitor offers a 10,000 uF capacitance with a voltage rating of 100 VDC and a tolerance of 20%. Designed with a snap-in, side view terminal PCB layout, it features RoHS compliance and halogen-free construction, making it suitable for various industrial and electronic applications. Operating within a temperature range of -40°C to +85°C and rated at 85°C, it boasts a long lifespan of up to 18,000 hours at rated voltage, with low equivalent series resistance and leakage current, ensuring reliable performance in demanding environments.
KEMET ALC70A103EH100 Electrolytic Capacitor Specifications:
- Capacitance: 10,000 uF
- Voltage DC: 100 VDC, 115 VDC (Surge)
- Capacitance Tolerance: 20%
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 40mm, Length 60mm
- Leakage Current: 6000 uA (5min 20°C)
- Ripple Current: 8.704 Amps (100Hz 85°C), 10.35 Amps (10kHz 85°C)
- Life Expectancy: 18000 hours at rated voltage and temperature
- Resistance: 2431 mOhms (100Hz 20°C), 28.67 mOhms (10kHz 20°C)
- Shell Material: Aluminum
- RoHS Compliant: Yes
- Halogen Free: Yes
- Lead Type: 2 Pin
- Packaging: Bulk, Bag
- Shelf Life: 156 Weeks
Buy the KEMET ALC70A103EH100 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Order the KEMET aluminum electrolytic capacitor with 10,000 uF capacitance and 100 VDC voltage rating today. Designed for demanding industrial applications, it features RoHS compliance, halogen-free construction, and a long operational life of up to 18,000 hours at 85°C. Its compact dimensions of 40mm diameter and 60mm length allow easy integration into various electronic assemblies. Built to ensure stability and low resistance, this capacitor provides dependable performance in high-temperature and high-ripple environments. Purchase online now for quick delivery and reliable service.
Get KEMET ALC70A103EH100 today—built for durability, long lifespan, and reliable performance in industrial and electronic circuits.
Frequently Asked Questions
Where can I buy KEMET ALC70A103EH100?
You can click on the BUY or RFQ button to purchase ALC70A103EH100 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALC70A103EH100?
You can download the ALC70A103EH100 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALC70A103EH100?
KEMET
