KEMET ALC80A331CD350 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor features a snap-in design with a capacitance of 330 uF, a voltage rating of 350 VDC (385 VDC surge), and a temperature range from -40°C to +105°C. Weighing 50 grams, it is RoHS compliant, halogen-free, and suitable for high-temperature applications. Its dimensions include a diameter of 30 mm and an adjustable length, with low ESR of 214.7 mΩ at 20°C. Designed for reliable operation, it offers a shelf life of 156 weeks and operates with ripple currents up to 5.07A at 10kHz, ensuring durability in demanding conditions.
KEMET ALC80A331CD350 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 330 uF
- Capacitance Tolerance: 20%
- Voltage DC: 350 VDC (surge 385 VDC)
- Temperature Range: -40°C to +105°C
- Rated Temperature: 105°C
- Dimensions: Diameter 30mm, length adjustable
- Weight: 50g
- Leakage Current: 346.5 uA at 20°C (5 min)
- Ripple Current: 5.07 Amps at 10kHz, 105°C
- Resistance: 214.7 mΩ at 20°C
Buy the Buy KEMET Aluminum Electrolytic Capacitor Part Number ALC80A331CD350 Online
Order the KEMET aluminum electrolytic capacitor with 330 microfarads at 350 volts today. Designed for high-temperature environments, it features RoHS compliance, halogen-free construction, and a robust 105°C rated temperature. Its compact size and low ESR make it ideal for power supplies, motor drives, and industrial equipment. With a shelf life of over three years and excellent ripple current handling capabilities, it offers dependable, long-lasting performance for demanding engineering solutions. Purchase online now for fast delivery and quality assurance.
Buy KEMET ALC80A331CD350 now and experience reliable performance in high-temperature and demanding electronic applications.
Frequently Asked Questions
Where can I buy KEMET ALC80A331CD350?
You can click on the BUY or RFQ button to purchase ALC80A331CD350 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALC80A331CD350?
You can download the ALC80A331CD350 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALC80A331CD350?
KEMET
