KEMET PEH532VBF3270M2 Aluminum Electrolytic Capacitor
The PEH532 series aluminum electrolytic capacitor features a snap-in design, 270 uF capacitance with 20% tolerance, and a rated voltage of 400 VDC. Operating temperature spans from -40°C to +105°C, making it suitable for high-temperature applications. It has a lead configuration with 2 pins, a weight of 30 grams, and a shelf life of approximately 208 weeks. Designed for reliable performance, it handles ripple currents up to 3 Amps at 20 kHz and 105°C, ensuring durability in demanding electronic systems.
KEMET PEH532VBF3270M2 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 270 uF
- Capacitance Tolerance: 20%
- Voltage DC: 400 VDC
- Temperature Range: -40°C to +105°C
- Rated Temperature: 105°C
- Dimensions: D 25mm +/-0.5mm
- Leakage Current: 324 uA (5min at 20°C)
- Ripple Current: Up to 3 Amps at 20kHz, 105°C
- Resistance: 420 mOhms (100Hz, 20°C), 260 mOhms (100kHz, 20°C)
- Shelf Life: 208 weeks
- Lead: 2 Pin
- Weight: 30g
Buy the KEMET Series PEH532 Aluminum Electrolytic Capacitor: PEH532VBF3270M2
Purchase the KEMET PEH532VBF3270M2 online today to ensure your electronic projects benefit from high-capacitance, high-voltage reliability, and excellent thermal stability. Designed for demanding power supply and filtering applications, this aluminum electrolytic capacitor offers outstanding durability, a wide operating temperature range, and low leakage current. Its snap-in construction allows easy installation, while its robust design ensures long-term performance. Get this high-quality capacitor now and enhance your electronic system’s efficiency and reliability with ease.
Buy KEMET PEH532VBF3270M2 now and experience unmatched reliability and high-temperature performance for power supply applications.
Frequently Asked Questions
Where can I buy KEMET PEH532VBF3270M2?
You can click on the BUY or RFQ button to purchase PEH532VBF3270M2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEH532VBF3270M2?
You can download the PEH532VBF3270M2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEH532VBF3270M2?
KEMET
