KEMET ALF70G912KP200 Aluminum Electrolytic Capacitor
The ALF70 series aluminum electrolytic capacitors by KEMET are high-capacitance, press-fit components designed for reliable power filtering and energy storage applications. Featuring a capacitance of 9,100 uF with a 20% tolerance and rated at 200 VDC, these capacitors operate effectively within a temperature range of -40°C to +85°C. They have a rugged design with press-fit 5-pin terminals, RoHS compliance, and a shelf life of up to 156 weeks. Suitable for various power electronic circuits, these capacitors ensure durability, low ESR, and consistent performance over extended periods.
KEMET ALF70G912KP200 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 9,100 uF
- Capacitance Tolerance: 20%
- Voltage DC: 200 VDC, 230 VDC (Surge)
- Operating Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 50mm, Length 105mm ±2mm
- Resistance at 100Hz 20°C: 22-47 mOhms
- Ripple Current at 85°C: 11.39 A (100Hz), 16.89 A (10kHz)
- Leakage Current: 6000 uA at 20°C
- Shelf Life: 156 Weeks
- Packaging: Bulk
- RoHS Compliant: Yes
- Halogen Free: Yes
- Lead: 5 Pin Press-Fit
- Dielectric: Aluminum Electrolytic
- Style: Press-Fit
- RoHS: Yes
Buy the KEMET Series ALF70 Aluminum Electrolytic Capacitor: ALF70G912KP200
Order the KEMET ALF70G912KP200 aluminum electrolytic capacitor online today. With a capacitance of 9,100 uF and voltage rating of 200 VDC, this press-fit component offers excellent durability, low ESR, and reliable performance for power supplies and electronic circuits. Its RoHS compliance, wide temperature range, and long shelf life make it ideal for industrial and commercial applications. Purchase now to ensure your projects benefit from high-quality, dependable energy storage components with quick delivery and excellent customer support.
Buy KEMET ALF70G912KP200 now and experience unmatched reliability and power stability for your electronic applications.
