KEMET A758KK827M0JAAE013 Polymer Aluminum Capacitor
The A758 series polymer aluminum capacitor features an 820 microfarad capacitance with 20% tolerance, operating at 6.3 VDC with surge capabilities up to 7.2 VDC. Designed for a wide temperature range of -55°C to +105°C, it offers a rated temperature of 105°C and a lifespan of 5000 hours at specified conditions. Its compact size includes dimensions of 8mm diameter, 8mm length, and 3.5mm lead spacing. Fully RoHS compliant, halogen-free, with wire leads, suitable for various electronic applications requiring reliable decoupling and filtering.
KEMET A758KK827M0JAAE013 Polymer Aluminum Capacitor Specifications:
- Capacitance: 820 uF
- Capacitance Tolerance: 20%
- Voltage DC: 6.3 VDC, Surge up to 7.2 VDC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Lifespan: 5000 hours at specified conditions
- Dissipation Factor: 10% at 120Hz 20°C
- Leakage Current: 774.9 uA (2min 20°C)
- Ripple Current: 4900 mA at 100kHz 105°C
- Dimensions: Diameter 8mm ±0.5mm, Length 8mm ±1mm, Lead Spacing 3.5mm ±0.5mm
- Lead: Wire leads, RoHS compliant, Halogen free
Buy the KEMET Series A758 Polymer Aluminum Capacitor: A758KK827M0JAAE013
Order the KEMET A758 series polymer aluminum capacitor online today and ensure reliable power management in your electronic circuits. With an 820uF capacitance, 6.3VDC voltage rating, and temperature range from -55°C to +105°C, this high-quality capacitor is ideal for demanding environments. Its compact size, wire lead configuration, RoHS compliance, and halogen-free construction make it suitable for a wide array of industrial and consumer electronics. Experience easy procurement, fast delivery, and trusted quality when you purchase this essential component online.
Buy KEMET A758KK827M0JAAE013 now and experience unmatched reliability and performance for your high-temperature electronic applications.
Frequently Asked Questions
Where can I buy KEMET A758KK827M0JAAE013?
You can click on the BUY or RFQ button to purchase A758KK827M0JAAE013 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A758KK827M0JAAE013?
You can download the A758KK827M0JAAE013 datasheet or visit the KEMET website for support.
Who is the manufacturer of A758KK827M0JAAE013?
KEMET
