KEYSIGHT TECHNOLOGIES N6731B DC Power Module
The Keysight N6731B is a compact, 50-watt basic DC power module offering 5V and 10A of programmable voltage and current. It features measurement and protection capabilities, making it ideal for automated test equipment systems used in R&D, design validation, and manufacturing. Supporting up to four outputs in a 1U rack space, its modular design enables system customization to optimize power and performance. Fast command processing and output response improve testing throughput. Connectivity includes GPIB, LAN, and USB, with full LXI Class C compliance, suited for general DC power and critical testing tasks.
KEYSIGHT TECHNOLOGIES N6731B DC Power Module Specifications:
- Output Rating: 5 V/10A/50 W
- Ripple & Noise: 20 mV p-p maximum
- Measurement Accuracy: 0.1% + 19 mV (voltage), 0.15% + 20 mA (current)
- Protection Features: Over-voltage, over-current, over-temperature
- Connectivity: GPIB, LAN (10/100 Base-T Ethernet), USB 2.0
- Compliance: LXI Class C
- Operating Environment: 0°C to 55°C, Up to 95% humidity, 2000 meters altitude
- Dimensions: 44.45 mm (height) x 432.5 mm (width) x 585.6 mm (depth)
- Weight: 12.73 kg / 28 lbs
Buy the Keysight N6700 – Reliable DC Power Modules for Industrial Applications
Discover the Keysight N6731B 50W DC power module, perfect for automated test setups. It offers adjustable 5V/10A outputs, measurement, protection, and seamless connectivity via GPIB, LAN, and USB. Compact and rack-mountable, it allows flexible system integration to meet diverse testing needs. Its advanced features improve throughput and reliability for R&D, validation, and manufacturing applications. Purchase online today to streamline your testing environment with trusted precision power modules from Keysight, ensuring optimal performance and system scalability.
Order your Keysight N6731B basic DC power module today and enhance your test system with reliable, flexible power solutions for R&D and manufacturing.
