KYOCERA AVX WBP3015W08U100D3B0A Dual Band Wi-Fi Antenna
The WBP3015W08-U100D3B0A is an embedded dual-band Wi-Fi antenna designed for 2.4 and 5 GHz applications, providing superior network coverage and reliable wireless connections. Its miniaturized form factor supports easy integration into access points, routers, gateways, and Wi-Fi-enabled TVs and monitors. The antenna features a PCB-compatible u.FL connector, lightweight design, and customizable options such as cable length and mounting preferences. Engineered for maximum system throughput and peak gain mitigation, it meets RoHS compliance for eco-friendly manufacturing in modern wireless devices.
KYOCERA AVX WBP3015W08U100D3B0A Dual Band Wi-Fi Antenna Specifications:
- Frequency: 2.4 GHz and 5 GHz bands
- Return Loss: < -8.4dB at 2.4 GHz, < 8.7dB at 5 GHz
- Efficiency: 65% at 2.4 GHz, 61% at 5 GHz
- Peak Gain: < 3 dBi at 2.4 GHz, < 6.7 dBi at 5 GHz
- Feed Point Impedance: 50 ohms unbalanced
- Size: 30.00 ± 0.15 mm length, 15.50 ± 0.15 mm width, 0.80 ± 0.05 mm thickness
- Cable Length: 100 mm
- Connector: u.FL compatible
- Mounting: Adhesive 3M468MP included
- Material: FR4 based antenna with PC/ABS housing, RoHS compliant
Buy the Ethertronics WXP3015W08-U100D3B0A – Reliable Dual Band Wi-Fi Antenna for Industrial Applications
Order the Ethertronics WXP3015W08-U100D3B0A today for seamless Wi-Fi connectivity in industrial and commercial devices. Its compact design ensures easy integration into access points, routers, gateways, and smart TVs, providing reliable 2.4 and 5 GHz coverage. Engineered for maximum system throughput, peak gain mitigation, and compliance with RoHS standards, this antenna boosts wireless performance and reliability across various applications. With customizable cable lengths and mounting options, it ensures perfect fitment and optimal signal strength for your wireless system deployments.
Get Ethertronics WXP3015W08-U100D3B0A today—built for high-performance Wi-Fi in industrial environments.
Frequently Asked Questions
Where can I buy KYOCERA AVX WBP3015W08U100D3B0A?
You can click on the BUY or RFQ button to purchase WBP3015W08U100D3B0A from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part WBP3015W08U100D3B0A?
You can download the WBP3015W08U100D3B0A datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of WBP3015W08U100D3B0A?
KYOCERA AVX
