KYOCERA AVX WCP3015W08U100D3B0A Wi-Fi Antenna
The WCP3015W08-U100D3B0A is an embedded dual-band Wi-Fi antenna designed for high-performance connectivity in compact electronic devices. It features a miniaturized 30x15 mm design with a 0.8 mm thickness, supporting 2.4 and 5 GHz frequency bands with high efficiency and low return loss. The antenna offers three radiation patterns for optimal positioning, ensuring superior network coverage, improved signal sensitivity, and better throughput. Compatible with u.fl connectors, it is RoHS compliant, making it ideal for routers, access points, gateways, and Wi-Fi-enabled TV and monitors.
KYOCERA AVX WCP3015W08U100D3B0A Wi-Fi Antenna Specifications:
- Frequency: 2.4 GHz and 5 GHz bands
- Return Loss: < -8.4dB and < 8.7dB
- Efficiency: 65% at 2.4 GHz, 61% at 5 GHz
- Peak Gain: < 3 dBi at 2.4 GHz, < 6.7 dBi at 5 GHz
- Impedance: 50 ohms unbalanced
- Size: 30.00 + 0.15 mm (length), 15.50 + 0.15 mm (width), 0.80 + 0.05 mm (thickness)
- Cable Length: 100 mm
- Connector: u.fl compatible
- Material: PC/ABS plastic
- Weight: Not specified
- Adhesive: 3M468MP
- RoHS Compliant
- Supports multiple radiation patterns: slant left, slant right, straight aligned with Z-axis
Buy the Ethertronics Series WXP Wi-Fi Antenna: WCP3015W08-U100D3B0A
Enhance your wireless device with the Ethertronics WCP3015W08-U100D3B0A dual-band Wi-Fi antenna. Its compact 30x15 mm size, high efficiency, and support for 2.4 and 5 GHz bands ensure reliable, fast wireless connections. Featuring three radiation patterns, it provides optimal signal coverage and throughput. Designed for easy integration with u.fl connectors and RoHS compliant materials, this antenna is perfect for routers, access points, gateways, and Wi-Fi-enabled TVs or monitors seeking superior wireless performance. Buy online today for seamless connectivity.
Buy Ethertronics WCP3015W08-U100D3B0A now and experience high-performance dual-band Wi-Fi connectivity with multiple radiation patterns and compact design.
