L-COM PT98930PV1E22B1C10G Pressure Transmitter
The PT989-30PV1E22B1C10G is a robust gauge pressure transmitter designed for industrial applications, offering 0-30psi measurement with 4-20mA output. Made from stainless steel with a compact, lightweight design, it features reverse polarity protection, short circuit protection, and is suitable for measuring various media. It operates between 11-28V DC, with an IP65 ingress protection rating, making it ideal for water management, chemical, metallurgy, and mining industries. Long-term stability and thermal accuracy ensure reliable performance over time.
L-COM PT98930PV1E22B1C10G Pressure Transmitter Specifications:
- Pressure Range: 0-30 psi
- Accuracy: 0.5% of Full Scale
- Zero Thermal Error: +0.03% Full Scale/°C
- Span Thermal Error: +0.03% Full Scale/°C
- Temperature Range: 0-50°C (compensated), -30°C to 80°C (operating), -40°C to 120°C (storage)
- Long Term Stability: +0.3% of Full Scale/year
- Overpressure: 1.5 x Full Scale
- Output Signal: 4-20mA
- Power Supply: 11-28V DC
- Ingress Protection: IP65
- Material: Diaphragm stainless steel 316L, Tubing stainless steel 304, Plug housing plastic, Pin Kovar, O-Ring Viton
- Electrical connection: DIN 43650 plug
- Process connection: NPT1/2 Male
- Certifications: ROHS and CE compliant
Buy the Infinitg PT989 Series – Reliable Pressure Transmitter for Industrial Applications
Order the PT989-30PV1E22B1C10G pressure transmitter online today and enhance your industrial pressure monitoring system. With a 0-30psi gauge range, 4-20mA output, and robust stainless steel construction, this device ensures accurate and stable readings in demanding environments. Its IP65 protection and CE compliance make it suitable for water management, chemical processing, mining, and metallurgy industries. Invest in this reliable pressure sensor now for long-term performance and seamless integration into your control system.
Buy Infinitg PT989-30PV1E22B1C10G now and experience unmatched reliability and performance in pressure measurement for industrial processes.
Frequently Asked Questions
Where can I buy L-COM PT98930PV1E22B1C10G?
You can click on the BUY or RFQ button to purchase PT98930PV1E22B1C10G from an authorized L-COM distributor.
How do I troubleshoot issues or seek technical support for part PT98930PV1E22B1C10G?
You can download the PT98930PV1E22B1C10G datasheet or visit the L-COM website for support.
Who is the manufacturer of PT98930PV1E22B1C10G?
L-COM
