Littelfuse 37014000410 Fast-Acting Electronic Fuse
The 370-series TR5® 4A 250VAC sub-miniature, fast-acting fuse features a thermoplastic polyamide base or cap with copper/tin-plated round pins and a radial leaded case. Designed to save PCB space, it offers both direct solder and plug-in options, low internal resistance, shock and vibration resistance, and complies with IEC 60127-3 standards. It operates within -40°C to 85°C, is halogen-free, lead-free, suitable for safety, power management, industrial, and consumer electronics, and supports versatile soldering and socket insertion methods.
Littelfuse 37014000410 Fast-Acting Electronic Fuse Specifications:
- Operating Voltage: 250VAC
- Current Rating: 4A
- Temperature Range: -40°C to +85°C
- Housing Material: Polyamide PA 6.6, UL 94V-0
- Pin Material: Copper, Tin-plated
- Lead Type: Radial leaded, direct solder or plug-in
- Certifications: IEC 60127-3, UL Recognized, Halogen-free, RoHS compliant
- Color: Brown
- Resistance: Low internal resistance
- Shock Resistance: Yes
- Vibration Resistance: Yes
- Soldering Parameters: 350°C for 5 sec maximum, hand soldering 2-5 sec at 350°C
- Mechanical: Lead pull strength tested to IEC 60068-2-21
Buy the Buy Litelfuse 370 Series TR5 Fuse Part Number 37014000410 Online
Get the trusted Litelfuse 370 Series TR5 fast-acting fuse online today. With a 4A capacity, 250VAC rating, and robust design, this fuse is ideal for power supplies, industrial controllers, and consumer electronics. Its compact size saves PCB space, while the halogen-free, lead-free construction ensures safety and compliance. Easy to solder or insert into plug-in sockets, it delivers dependable performance by protecting circuits from overcurrent conditions. Purchase now to enhance your device safety and reliability.
Order your Litelfuse Series370 TR5 fuse part number 37014000410 today and ensure reliable overcurrent protection for your electronic systems.
Frequently Asked Questions
Where can I buy Littelfuse 37014000410?
You can click on the BUY or RFQ button to purchase 37014000410 from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 37014000410?
You can download the 37014000410 datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 37014000410?
Littelfuse
