Littelfuse FS126RC Low Current Flasher
The FS126RC series low current flasher controls are solid-state devices designed to manage inductive, incandescent, or resistive loads with reliability. Operating with an input of 120VAC, they feature a fullwave AC output rated at 1A steady state and a 10A inrush capacity, ideal for tower lighting and warning signals. These flashers offer a fixed flash rate of 75 FPM with options for custom rates from 45 to 150 FPM. Compact and easy to install, they provide consistent flashing for industrial and OEM applications, ensuring durability and performance in demanding environments.
Littelfuse FS126RC Low Current Flasher Specifications:
- Input Voltage: 120VAC +15%
- Output Rating: 1A fullwave AC steady state, 10A inrush
- Maximum Load Rating: 1A fullwave, 2A halfwave
- Flash Rate: Fixed at 75 FPM, customizable from 45 to 150 FPM
- ON/OFF Ratio: 50%
- AC Line Frequency: 50/60Hz
- Dimensions: Height 38.1mm (1.5 inches), Width 23.9mm (0.94 inches)
- Mounting: Removable bracket with #8 (M4 x 0.7) screw
- Operating Temperature: -20°C to 60°C
- Storage Temperature: -40°C to 85°C
- Humidity: 95% non-condensing
- Weight: 31g
Buy the Buy Littelfuse FS126RC Part Number FS126RC Online
Experience dependable tower lighting with the Littelfuse FS126RC low current flasher. Designed for inductive, incandescent, and resistive loads, it features a 120VAC input, a fixed flash rate of 75 FPM or custom rates from 45 to 150 FPM. With a steady 1A output and 10A inrush capacity, it offers compact installation with durable solid-state performance. Perfect for OEM and industrial applications, this flasher ensures consistent, reliable operation in demanding environments, enhancing safety and visibility in critical lighting systems.
Order your Littelfuse FS126RC series flasher today and ensure reliable tower lighting with consistent, high-quality flashing performance.
Frequently Asked Questions
Where can I buy Littelfuse FS126RC?
You can click on the BUY or RFQ button to purchase FS126RC from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part FS126RC?
You can download the FS126RC datasheet or visit the Littelfuse website for support.
Who is the manufacturer of FS126RC?
Littelfuse
