Littelfuse PSR030DL0050Z Semiconductor Fuse
Littelfuse PSR series high-speed square body fuse offers rapid protection for power semiconductor devices such as diodes, IGBTs, and MOSFETs used in power conversion and conditioning equipment. Designed with DIN 43653 blade terminals, these fuses feature visual blown fuse indication and optional micro-switch for external signaling. They deliver excellent current limiting, fast response times (10 ms), and are suitable for applications like UPS, inverters, drives, and electric vehicle chargers, ensuring reliable circuit protection aligned with global safety standards including UL, IEC, and CCC.
Littelfuse PSR030DL0050Z Semiconductor Fuse Specifications:
- Voltage Rating AC: 550 V - 1300 V
- Voltage Rating DC: 480 V - 1000 V
- Amperage Rating: 40 A - 2000 A
- Interrupting Rating AC: 100 kA - 200 kA
- Interrupting Rating DC: 150 kA
- Time Constant: 10 ms
- Body Material: Ceramic
- Contacts: Plated copper
- Mounting: DIN 43653 blade style
- Operating Temperature: -55°C to +125°C
- Certifications: UL Recognized, cUL, IEC 60269-4 Class aR, RoHS, REACH
Buy the Littelfuse PSR030DL0050Z – Reliable High-Speed Semiconductors Fuse for Industrial Applications
Order the Littelfuse PSR series high-speed fuse online today and ensure robust circuit protection for power semiconductor devices. Ideal for UPS, drives, inverters, and electric vehicle chargers, these fuses provide fast response (10 ms), high current limiting, visual blown indication, and optional micro-switch signaling. Manufactured with ceramic bodies and copper contacts, they are certified to UL, IEC, and CCC standards. Secure your power systems with this reliable, easy-to-install fuse solution designed for demanding industrial environments, ensuring safety and operational efficiency.
Buy Littelfuse PSR030DL0050Z now and experience unmatched reliability and performance in protection of power semiconductor devices.
Frequently Asked Questions
Where can I buy Littelfuse PSR030DL0050Z?
You can click on the BUY or RFQ button to purchase PSR030DL0050Z from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part PSR030DL0050Z?
You can download the PSR030DL0050Z datasheet or visit the Littelfuse website for support.
Who is the manufacturer of PSR030DL0050Z?
Littelfuse
