Littelfuse PSR070DL0200Z Semiconductor Fuse
The high-speed semiconductor fuse features a square ceramic body with DIN 43653 blade mounting, suitable for protecting power diodes, IGBTs, and other solid-state devices in power conversion systems. It offers extremely fast interruption, current limiting, and visual blown fuse indication with optional micro-switch. Certified for use in varied electrical applications including UPS, drives, and electric vehicle chargers, this fuse operates at voltages up to 1300V AC/DC, current ratings from 40A to 2000A, and features a quick response time of 10 ms for reliable circuit protection.
Littelfuse PSR070DL0200Z Semiconductor Fuse Specifications:
- Voltage Rating AC: 550 V-1300V
- Voltage Rating DC: 480 V-1000 V
- Amperage Rating: 40 A-2000 A
- Interrupting Rating AC: 100 KA-200 kA
- Interrupting Rating DC: 150 kA
- Time Constant: 10 ms
- Mounting: DIN 43653 blade style
- Material Body: ceramic
- Contacts: plated copper
- Operating Temperature: -60°C to +125°C
- Approval: UL 248-13 Recognized, cURus, IEC 60269-4, RoHS, REACH
- Environmental: Up to +35°C with <65% humidity
Buy the Littelfuse Series PSR Semiconductor Fuse: PSR070DL0200Z
Protect your power semiconductor devices with the Littelfuse high-speed semiconductor fuse designed for power conversion systems. The ceramic square body fuse offers rapid response times of 10 ms, high current limiting, and visual blown fuse indication with optional micro-switch for external alert. Rated up to 1300V and 2000A, it ensures reliable protection in UPS, drives, and electric vehicle chargers. Certified by UL, cURus, and IEC standards, this fuse is essential for safeguarding sensitive solid-state components against overcurrent and surges, promoting system safety and durability.
Get Littelfuse PSR070DL0200Z today—built for high-speed circuit protection in power electronics and industrial applications.
Frequently Asked Questions
Where can I buy Littelfuse PSR070DL0200Z?
You can click on the BUY or RFQ button to purchase PSR070DL0200Z from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part PSR070DL0200Z?
You can download the PSR070DL0200Z datasheet or visit the Littelfuse website for support.
Who is the manufacturer of PSR070DL0200Z?
Littelfuse
