LUMBERG WSV80 Industrial Circular Connector
The WSV80 connector is a robust circular connector designed for various industrial applications, featuring a 12-pole configuration with a pre-nickel, gold-plated contact pin, and a durable PA GF insulating body. It supports operating temperatures from -40°C to +85°C, with a rated current of 3A at 40°C and a rated voltage of 250V. Its compact size allows easy installation with a maximum tightening torque of 13 Nm. Suitable for environments requiring secure, high-quality connections with IP40 protection class in locked condition.
LUMBERG WSV80 Industrial Circular Connector Specifications:
- Insulating body: PA GF, V-0 rated according to UL94
- Contact pin: CuZn, pre-nickel and gold-plated
- Ground contact spring: CuZn, pre-nickel and gold-plated
- Housing: PC, HB according to UL94
- Strain relief: TPE
- Tightening torque connector: 13 Nm
- Protection class: IP40 in locked condition according to IEC DIN EN 60529
- Rated current: 3A at 40°C
- Rated voltage: 250V
- Rated impulse voltage: 1500V
- Cable diameter: 4-6 mm
- Operating temperature: -40°C to +85°C
Buy the Lumberg Series WSV: Circular Connector 12-Pole IP40/IP67/IP68
Enhance your projects with the durable and reliable Lumberg Series WSV80 circular connector, featuring a 12-pole configuration, gold-plated contacts, and a robust insulating body. Designed for industrial environments, it operates between -40°C and +85°C, rated at 3A and 250V. With IP40 protection in locked condition, it allows secure connections with a maximum tightening torque of 13 Nm. Pre-assembled and packed in a cardboard box, this connector ensures quick installation and long-lasting performance for your automation, control, and instrumentation applications.
Order your Lumberg Series WSV80 connector today and ensure reliable, high-quality connections tailored for your industrial needs.
Frequently Asked Questions
Where can I buy LUMBERG WSV80?
You can click on the BUY or RFQ button to purchase WSV80 from an authorized LUMBERG distributor.
How do I troubleshoot issues or seek technical support for part WSV80?
You can download the WSV80 datasheet or visit the LUMBERG website for support.
Who is the manufacturer of WSV80?
LUMBERG
