MAXIM INTEGRATED / ANALOG DEVICES MAX11198EVKIT Analog-to-Digital Converter
The MAX11198EVKIT evaluation kit from Maxim Integrated is designed for testing the MAX11198, a 16-bit, two-channel, 2Msps, fully differential successive approximation register (SAR) analog-to-digital converter with an internal reference. The kit includes a pre-assembled evaluation board featuring the MAX11198ATE+ in a 16-pin, 2mm x 3mm TQFN-EP package. It provides a user-friendly graphical interface for communication via a ZedBoard equipped with a Xilinx Zynq-7000 SoC and connects to a PC through an Ethernet port. The kit supports various sampling rates and sizes, can collect up to one million samples, and includes features like sync-in and sync-out for coherent sampling, onboard differential input buffers, and external reference options. Suitable for applications such as motor current sensing, encoders, resolvers, LVDT, and PLCs, the fully assembled, tested kit offers flexible power options and Windows compatibility, making it ideal for precision measurement and data acquisition tasks in industrial and automation environments.
MAXIM INTEGRATED / ANALOG DEVICES MAX11198EVKIT Analog-to-Digital Converter Specifications:
- Resolution: 16-bit
- Channels: 2 fully differential inputs
- Sampling Rate: up to 2MSps
- Input Type: Fully differential
- Input Buffers: Onboard MAX44242 and MAX44205
- Reference Voltage: Internal 2.5V, external 2.5V to 4.75V
- Package: 16-pin, 2mm x 3mm TQFN-EP
- Communication: 50MHz SPI over FMC connector
- Sample Memory: Up to 1,048,576 samples (1 million)
- Power Supply: +12V from external or ZedBoard, options for external 1.8V–3.6V reference voltage
- Features: Sync In/Out for coherent sampling, Windows-compatible GUI, fully assembled and tested
- Applications: Industrial measurement, motor control, encoders, resolvers, sensors, PLCs
