MAXIM INTEGRATED / ANALOG DEVICES MAX14130FAEE digital isolator
The MAX14130FAEE is a 4-channel digital isolator capable of handling signals up to 1kVRms, ideal for isolating digital signals between different power domains. It supports data rates up to 150Mbps, features low power consumption, and withstands high transient voltages including 3.75kVpms for 60 seconds. Suitable for industrial automation, medical systems, and communication applications, it offers unidirectional channels, independent level shifting from 1.71V to 5.5V, and complies with UL1577 safety standards, ensuring reliable galvanic isolation and high EMI immunity.
MAXIM INTEGRATED / ANALOG DEVICES MAX14130FAEE digital isolator Specifications:
- Number of channels: 4
- Isolation voltage: 1kVRms
- Data rate: up to 150Mbps
- Supply voltage: 1.71V to 5.5V
- Maximum continuous isolation voltage: 424Vpeaxk
- Transient voltage immunity: up to 3.75kVpms for 60 seconds
- Operating temperature: -40°C to +125°C
- Package: 16-pin QSOP
- Standards: UL1577, CSA, pending VDE 0884-10
- Insulation resistance: >10 Qa at 500V
- Leakage current: minimal
- Barrier capacitance: approx. 2pF
Buy the Maxim Series MAX14930 Digital Isolator: MAX14130FAEE
Enhance your electronic system with the Maxim Series MAX14130FAEE digital isolator, offering 150Mbps data rate and 1kVRms galvanic isolation. Its wide supply voltage range from 1.71V to 5.5V enables flexible level shifting and power domain separation. Designed for applications requiring high transient voltage immunity, it meets UL1577 standards for safety and offers low power consumption. Perfect for industrial automation, communication, and medical systems, this device guarantees high EMI immunity, operational stability, and reliable signal integrity in challenging environments.
Order your Maxim Series MAX14130FAEE digital isolator today and ensure reliable high-speed signal isolation for industrial automation and medical systems.
