MAXIM INTEGRATED / ANALOG DEVICES MAX338CSET Analog Multiplexer
The MAX338CSE+T from Maxim Integrated Products is an 8-channel, low-leakage CMOS analog multiplexer in a 16-pin NSOIC package. Designed to connect one of 8 inputs to a common output via a 3-bit binary address, it features extremely low off leakage (less than 20pA at 25°C) and low on-channel leakage (less than 50pA). The device offers low charge injection (1.5pC) and ESD protection exceeding 2000V, with TTL-compatible control inputs over wide temperature and supply ranges. Suitable for data acquisition, test equipment, and military applications, it supports supply voltages from 4.5V to 30V, operates from 0°C to 70°C, and has a transition time under 500ns. Other features include rail-to-rail signal handling, maximum on-resistance of 650Ω at 25°C, and channel resistance matching within 10Ω, making it ideal for guidance, communication, and head-up display systems.
MAXIM INTEGRATED / ANALOG DEVICES MAX338CSET Analog Multiplexer Specifications:
- On-Resistance: <650Ω at 25°C
- Leakage Current: <20pA off, <50pA on at 25°C
- Charge Injection: 1.5pC typ
- ESD Protection: >2000V
- Supply Voltage Range: 4.5V to 30V
- Operating Temperature: 0°C to 70°C
- Transition Time: <500ns
- Control Inputs: TTL compatible (+0.8V to +2.4V)
- On-Resistance Match: within 10Ω
- Off Isolation: -75dB
- Crosstalk: -92dB at 100kHz
- Package: 16-pin NSOIC
- Device Fabrication: Maxim's 44V silicon gate process
- Application: Data acquisition, guidance, test, military, communication
- Supports single and bipolar supply operation
Buy the Buy Maxim MAX338CSET Part Number MAX338CSET Online
Experience unmatched performance with the Maxim MAX338CSET 8-channel CMOS analog multiplexer. Its low leakage, fast transition time, and wide supply voltage support make it ideal for high-precision data acquisition, guidance, and communication systems. Designed for reliability, this device features low charge injection and robust ESD protection, ensuring durability across various operating conditions. Whether used as a multiplexer or demultiplexer, the MAX338CSET delivers seamless operation in military, test, and industrial environments. Easily order online and enhance your system’s performance with this industry-standard component.
Get Maxim MAX338CSET today—built for precision, low leakage, and high reliability in analog multiplexing applications.
