MAXIM INTEGRATED / ANALOG DEVICES MAXREFDES23DB Industrial multi-sensor module
The Santa Cruz IO-Link Light Sensor is the world's smallest multi-sensor device measuring 6.5mm x 25mm, compliant with IEC 61131-9. It integrates ambient light, red, green, blue, infrared, and temperature sensors on a compact PCB. Powered by a low-power RL78 microcontroller and a MAX14821 transceiver, it offers robust industrial performance with reverse polarity and short-circuit protection. Ideal for space-constrained industrial automation applications, it simplifies wiring with an M12 connector and supports cyclic data exchange every 2ms, ensuring reliable, real-time environment sensing for various industrial processes.
MAXIM INTEGRATED / ANALOG DEVICES MAXREFDES23DB Industrial multi-sensor module Specifications:
- Size: 6.5mm x 25mm PCB
- Sensor Types: Ambient light, red, green, blue, infrared, temperature
- Microcontroller: RL78, 64KB flash, 4KB data flash, 1.8V operation
- Transceiver: MAX14821, 2.5mm x 2.5mm WLP package
- Light Sensor: MAX44008, 14-bit ADC, dedicated PGA, 2mm x 2mm package
- Communication: IO-Link v1.1/1.0, 230.4kbps
- Protection: Reverse polarity, short-circuit, ESD TVS diodes meeting IEC 61000-4-2
- Power: Low power consumption, less than 12mA typical
- Connector: M12 circular, 4-wire or 3-wire cable compatible
- Operating Voltage: 18V-30V, typical 24V system
- Environmental: Designed to meet harsh industrial conditions
- Cycle Time: Data exchange every 2ms
- Certifications: IEC 61131-9, UL, CSA
Buy the Maxim Series Santa Cruz IO-Link Light Sensor: MAXREFDES23#
Order Maxim's Santa Cruz multi-sensor module online today to enhance your industrial automation projects. Measuring just 6.5mm x 25mm, it combines ambient light, RGB, infrared, and temperature sensing on a robust PCB. Equipped with low-power microcontroller and industry-standard transceivers, this sensor offers reliable real-time data exchange via IO-Link at a cycle of 2ms. Perfect for space-limited environments, it simplifies wiring with M12 connectors and provides protection against electrical transients. Ideal for industrial light sensing, automation, and process monitoring.
Get Maxim Maxim Series Santa Cruz IO-Link Light Sensor today—compact, energy-efficient, ideal for industrial automation and process control.
