MEAN WELL APV3512 LED Power Supply
The APV-35 series by MEAN WELL offers reliable 30W single output switching power supplies. Designed for LED fixtures or appliances, these compact, IP42-rated units feature full-range universal AC input, surge withstand capability of 300VAC for 5 seconds, and comprehensive protections including short circuit, overload, and overvoltage. With high efficiency up to 85%, they ensure minimal energy loss and generate minimal ripple and noise. These power supplies operate reliably within a broad temperature range of -30°C to 70°C, making them ideal for outdoor or harsh environments, and meet various safety and EMC standards for safe, compliant installation.
MEAN WELL APV3512 LED Power Supply Specifications:
- Power Output: 30W
- Input Voltage: 90~264VAC, 127~370VDC
- Output Voltage Options: 12V, 18V, 24V, 36V
- Rated Current: 5A (12V), 3A (18V), 2.4A (24V), 1.5A (36V)
- Efficiency: Up to 85%
- Ripple & Noise: Max. 120mVp-p (12V), 450mVp-p (18V/24V), 180mVp-p (36V)
- Protections: Short circuit, Over load (110%-160%), Overvoltage
- Operating Temperature: -30°C to 70°C (derating required above 50°C)
- Humidity Range: 20-90% RH non-condensing
- Safety & EMC Standards: UL, CSA, EN60950-1, EN55032, EN61000-4
- Isolation Resistance: >100MΩ at 500VDC
Buy the Buy MEAN WELL APV-35-12 LED Power Supply Part Number APV3512 Online
Order the MEAN WELL APV-35-12 LED power supply online now for reliable, efficient operation in outdoor and indoor lighting environments. Designed with full protection features, compact size, and high efficiency, this power supply ensures optimal performance for LED fixtures, decoration, or advertising displays. Its robust build and wide voltage range make it suitable for various applications, while the 2-year warranty guarantees peace of mind. Shop now for a cost-effective, durable power solution that meets safety standards and enhances your lighting system.
Get MEAN WELL APV-35-12 today—built for precision and long-lasting durability in LED and lighting applications.
Frequently Asked Questions
Where can I buy MEAN WELL APV3512?
You can click on the BUY or RFQ button to purchase APV3512 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part APV3512?
You can download the APV3512 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of APV3512?
MEAN WELL
