MEAN WELL DDR15G33 Industrial DC-DC Converter
The DDR-15G33 is a 15W DIN Rail DC-DC converter designed for industrial applications, featuring ultra-wide input voltage range, -40°C to +85°C operating temperature, and reinforced 4KVdc I/O isolation. It offers adjustable output voltage (+10%), multiple protections including overload and reverse polarity, and can be installed easily on TS-35 DIN rails. Suitable for control systems, communication, and automation, this compact power supply ensures reliable performance in harsh environments with high efficiency and full safety standards compliance.
MEAN WELL DDR15G33 Industrial DC-DC Converter Specifications:
- Power: 15W
- Input Voltage Range: 9-36V / 18-75V
- Output Voltages: 3.3V, 5V, 12V, 15V, 24V
- Rated Current: 3.54A (3.3V), 3A (5V), 1.25A (12V), 1A (15V), 0.63A (24V)
- Ripple & Noise: Max 50mVp-p to 400mVp-p depending on model
- Voltage Adjustment Range: 30-36V, 45-5.5V, 9-13.2V, 13.5-16.5V, 21.6-28V
- Voltage Tolerance: ±2.0%
- Line & Load Regulation: 0.5% to 1%
- Temperature Range: -40°C to +85°C
- Isolation Voltage: 4KVdc / reinforced
- Dimensions: 17.5mm (W) x 90mm (H) x 54.5mm (D)
- Efficiency: 84-86%
- Protections: Short circuit, overload, over voltage, reverse polarity, under voltage lockout
- Standards: IEC 62368-1, UL508, EMC compliant, high MTBF
- Vibration & Humidity: 10-500Hz, 2G; 5-95% RH non-condensing
- Operating Altitude: up to 2000 meters
Buy the Buy Meanwell DDR-15G33 Part Number DDR15G33 Online
Purchase the high-performance DIN Rail DC-DC converter online to ensure your industrial automation, communication, and control systems operate with stable power supply. Compact and easy to install on TS-35 rails, it features an ultra-wide input range, adjustable output, high-temperature tolerance, and comprehensive protections, making it ideal for challenging environments. Depend on this reliable power module for consistent operation, energy efficiency, and safety compliance—getting it online offers rapid delivery and excellent support for your technical needs.
Buy Meanwell DDR-15G33 now and experience unmatched reliability and high efficiency for industrial control and automation systems.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15G33?
You can click on the BUY or RFQ button to purchase DDR15G33 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15G33?
You can download the DDR15G33 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15G33?
MEAN WELL
