MEAN WELL OWA60E42 Moistureproof Power Supply
The moistureproof power supply series delivers 60W of reliable DC output in a fully sealed, IP67-rated enclosure, suitable for damp, dusty, or humid environments. It features high efficiency up to 91%, low no-load power consumption under 0.15W, and complies with EU ErP and CoC standards. With universal AC input (90-264VAC), it supports a wide temperature range from -35°C to +70°C and includes protections against short circuits, overloads, overvoltage, and overtemperature. Its fanless, fully isolated plastic case ensures durability and safety for outdoor or industrial applications such as household appliances, battery charging, and robotic lawn mowers.
MEAN WELL OWA60E42 Moistureproof Power Supply Specifications:
- Output Power: 60W
- Output Voltage: 12V, 15V, 20V, 24V, 30V, 36V, 42V, 48V, 54V (depending on model)
- Rated Current: 5A, 4A, 3.25A, 2A, 1.674A, 1.5A, 1.254A, 4.124A, 1.111A (depending on model)
- Ripple & Noise: Max. 150mVp-p to 350mVp-p depending on model
- Voltage Tolerance: ±4%, ±4%, +3%, +3%, ±2%, ±1%, ±1%, ±1%, ±1% (depending on model)
- Line Regulation: ±1%, ±1%, ±1%, ±1%, ±1%, ±1%, ±1%, ±1%, ±1%
- Load Regulation: ±1.5% or ±1.0%, depending on model
- Efficiency: Up to 91%, typical 88% - 90%
- Input Voltage Range: 90VAC to 264VAC
- Frequency Range: 47Hz to 63Hz
- Operating Temperature: -35°C to +70°C
- Storage Temperature: -40°C to +80°C
- Protection: Short circuit, Overload, Overvoltage, Over temperature; Hiccup mode for fault recovery
- Safety Standards: EN61558-1, EN61558-2-16, EN60335-1 (for some models), IP67 rated enclosure
- Cooling Method: Fanless convection
- Dimensions: Approximately 130mm x 53mm x 35mm
Buy the Mean Well OWA-60E – Reliable Moistureproof Power Supply for Industrial Applications
Discover the robust and efficient moistureproof power supply ideal for outdoor industrial use. With IP67 sealing, high efficiency up to 91%, and multiple safety protections, it ensures reliable operation in dusty, humid, or damp environments. Its fully isolated plastic case and fanless convection cooling guarantee durability and safety, suitable for applications like household appliances, battery charging, and robotic lawn mowers. Get your reliable power solution today and enjoy seamless performance in challenging conditions.
Buy Mean Well OWA-60E now and experience unmatched reliability and performance in harsh environments with dust, humidity, and dust-resistant design.
Frequently Asked Questions
Where can I buy MEAN WELL OWA60E42?
You can click on the BUY or RFQ button to purchase OWA60E42 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part OWA60E42?
You can download the OWA60E42 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of OWA60E42?
MEAN WELL
