MEAN WELL DDR30L15 industrial power module
The DDR-30L-15 is a 30W DIN rail DC-DC converter designed for industrial applications, offering ultra-wide input ranges of 18-75V and various outputs including 15V. Its compact, slim profile of 35mm width makes installation on standard TS-35/7.5 or 15 DIN rails straightforward. The device supports a wide operating temperature of -40°C to +85°C, features reinforced 4KVdc I/O isolation, and provides protections such as short circuit, overload, over-voltage, reverse polarity, and under-voltage lockout. Suitable for factory automation, communication systems, control equipment, and security systems, it ensures reliable, stable power conversion with high efficiency and full safety standards compliance.
MEAN WELL DDR30L15 industrial power module Specifications:
- Power: 30W
- Input Voltage Range: 18-75VDC (L type)
- Output Voltage: 15VDC
- Rated Current: 2A
- Ripple & Noise: 75mVp-p maximum
- Voltage Adjustment Range: 13.5~16.5V
- Voltage Tolerance: ±2.0%
- Line Regulation: ±0.5%
- Load Regulation: ±0.5%
- Efficiency: 86%
- Setup & Rise Time: 85ms at full load
- Hold Up Time: 18ms@48V input
- Operating Temperature: -40°C to +85°C
- Humidity: 5~95% RH non-condensing
- Isolation Voltage: 4KVdc
- Dimension: 35mm width, length 90mm, height 54.5mm
- MTBF: 483,300 hours
- Certification: IEC 62968-1, UL508 design reference
- Vibrations: 10-500Hz, 2G
- Operating Altitude: Up to 2000 meters
Buy the Mean Well Series DDR-30 15V Industrial Power Module: DDR30L15
Order the Mean Well DDR30L15 now to ensure your industrial control systems, automation, and communication equipment are powered reliably. This 30W DIN rail mounted converter supports wide input voltage, operates seamlessly from -40 to +85°C, and offers high isolation for safety. Its compact design fits standard DIN rails, making installation straightforward. With protections against short circuits, overloads, and over-voltage, and efficiency up to 86%, it guarantees stable power delivery, meets safety standards, and enhances system durability. Purchase online today for quick, secure delivery and technical support.
Buy Mean Well DDR30L15 now and experience unmatched reliability and performance suitable for industrial control and communication systems.
Frequently Asked Questions
Where can I buy MEAN WELL DDR30L15?
You can click on the BUY or RFQ button to purchase DDR30L15 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR30L15?
You can download the DDR30L15 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR30L15?
MEAN WELL
