MEAN WELL GSM120B24R7B Medical Power Adapter
GSM120B is a highly reliable, 120W medical power adapter designed for various healthcare and medical devices requiring high efficiency and safety standards. It covers input voltage from 80VAC to 264VAC and outputs between 12VDC and 48VDC. Built with a 2-pin IEC320-C8 inlet and fully compliant with international safety standards, the adapter features ultra-low leakage current (<100uA), high efficiency up to 91.5%, and low no-load power consumption below 0.15W. It is suitable for applications such as portable hemodialysis, medical monitors, and BF-rated systems, ensuring safe, stable power supply in medical environments.
MEAN WELL GSM120B24R7B Medical Power Adapter Specifications:
- Input Voltage: 80VAC to 264VAC, 47~63Hz
- Output Voltage: 12V, 18V, 20V, 24V, 48V
- Rated Power: 102W, 105W, 172W, 172W, 120W
- Output Current: 8.5A, 7A, 6A, 5A, 25A
- Ripple & Noise (max): 120mVp-p, 150mVp-p, 180mVp-p, 200mVp-p, 240mVp-p
- Efficiency (Typ): 88%, 89%, 90%, 91.5%
- Leakage Current: <100uA at 264VAC
- Protection: Short circuit, Overload, Over voltage, Over temperature
- Operating Temperature: -30°C to +60°C
- Build: Fully enclosed plastic case, Class II power (no earth pin), UL 60601-1/EN60601-1 safety standards
- Dimensions: 167.7 x 67 x 35mm
- Safety & Isolation: 2x MOPP, Meets international medical safety standards
- Certification: UL, TUV, EN60601-1, FCC, CE
- Warranty: 3 years
Buy the GSM120B – Reliable Medical Power Adapter for Industrial Applications
Purchase the GSM120B medical power adapter online today for reliable, efficient, and safe power supply to medical devices. Designed to meet international safety standards, it offers ultra-low leakage current, high efficiency, and low no-load power consumption, perfect for critical applications like portable hemodialysis and medical monitors. Its robust plastic case, comprehensive protections, and 3-year warranty ensure long-lasting performance and safety compliance. Order now and ensure your medical equipment operates with consistent power, maximizing patient safety and device performance.
Get GSM120B today—built for high reliability, efficiency, and safety in medical and industrial environments.
Frequently Asked Questions
Where can I buy MEAN WELL GSM120B24R7B?
You can click on the BUY or RFQ button to purchase GSM120B24R7B from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part GSM120B24R7B?
You can download the GSM120B24R7B datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of GSM120B24R7B?
MEAN WELL
