MEAN WELL HEP10054A Industrial Power Supply
HEP-100 is a robust 100W industrial power supply designed for harsh environments involving dust, moisture, and vibrations. Featuring an aluminum case fully potted with heat-conducting silicone, it offers high efficiency up to 93% and operates from -55°C to +70°C using free air convection. The IP65-rated model is suitable for outdoor telecommunication, electronic signage, and petroleum plants. Optional IP68 models are available. It provides protections against short circuits, overloads, overvoltage, and temperature extremes, ensuring reliable operation in demanding conditions.
MEAN WELL HEP10054A Industrial Power Supply Specifications:
- Input Voltage: 90 ~ 305VAC / 127 ~ 431VDC
- Input Frequency: 47 ~ 63Hz
- Output Voltage Options: 12V, 15V, 24V, 36V, 48V, 54V
- Rated Power: 100W
- Efficiency: Up to 93%
- Operating Temperature: -55°C to +70°C
- Housing: Aluminum case, fully potted with heat-conducted silicone
- Ingress Protection: IP65, optional IP68 rated model available
- Surge Immunity Level: 6KV
- Vibration Resistance: 10G
- Protection Features: Short circuit, overload, over voltage, over temperature
- Altitude: Up to 5000 meters
- Dimensions: Approx. 220mm x 68mm x 38.8mm
- MTBF: 164.7K hours
Buy the Buy Mean Well HEP-100 Series Power Supply Part Number HEP10054A Online
Secure your project with the reliable 100W industrial power supply. The HEP-100 series offers high efficiency up to 93%, wide operating temperature from -55°C to +70°C, and robust IP65/IP68 rated protection for outdoor applications. Its aluminum case with heat conduction silicone ensures durability. These power supplies include protections for short circuits, overloads, and overvoltage, making them ideal for telecommunications, signage, and demanding industrial environments. Purchase online now for fast delivery and dependable quality.
Order your Mean Well HEP-100 Series power supply with adjustable voltage today and ensure reliable performance in harsh outdoor environments.
Frequently Asked Questions
Where can I buy MEAN WELL HEP10054A?
You can click on the BUY or RFQ button to purchase HEP10054A from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HEP10054A?
You can download the HEP10054A datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HEP10054A?
MEAN WELL
