MEAN WELL HRP30036 Power Supply
The HRP-300-36 is a high-efficiency 300W single-output power supply with active PFC, suitable for industrial automation, LED lighting, and control systems. It features full-range universal AC input, built-in protections including short circuit, overload, over-voltage, and over-temperature, and a built-in cooling fan with ON-OFF control. Its compact 1U low profile design measures 199*410.5*41mm, offers adjustable output voltage from 21.6V to 28.8V, and operates efficiently at up to 89%. It includes a DC OK signal, remote sense, and withstands surges up to 300VAC for 5 seconds, ensuring reliable performance in demanding environments.
MEAN WELL HRP30036 Power Supply Specifications:
- Power Rating: 300W
- Output Voltage Range: 21.6~28.8V adjustable
- Output Current: 0~7A
- Input Voltage Range: 85~264VAC / 120~370VDC
- Efficiency: up to 89%
- Ripple & Noise: 250mVp-p
- Dimensions: 199*410.5*41mm (L*W*H)
- Protections: Short circuit, Overload (105-135%), Over voltage, Over temperature
- Built-in active Power Factor Correction (PF>0.95)
- Cooling: Built-in fan ON-OFF control
- Surge withstand: 300VAC for 5 seconds
- Operating Temperature: -40°C to +70°C
- Humidity: 20%-90% RH non-condensing
- Certifications: UL, TUV, EAC, AS/NZS
- MTBF: 176,000 hours
- Vibration: 10-500Hz, 5G for 60 min each axis
Buy the Buy Mean Well HRP-300-36 Power Supply Part Number HRP30036 Online
Secure your industrial automation projects with the trustworthy HRP-300-36 power supply from Mean Well. This 300W unit offers high efficiency up to 89%, built-in active PFC, and robust protections against short circuits, overload, over-voltage, and temperature exceeding limits. Its compact design measures just 199mm by 410.5mm by 41mm, making it ideal for space-constrained environments. With adjustable output voltage, surge withstand ability, and a built-in cooling fan, this power supply ensures reliable operation in demanding applications. Purchase online now for fast delivery and dependable power.
Order your Mean Well HRP-300-36 power supply today and enjoy reliable performance with high efficiency, comprehensive protections, and flexible adjustable voltage for industrial projects.
Frequently Asked Questions
Where can I buy MEAN WELL HRP30036?
You can click on the BUY or RFQ button to purchase HRP30036 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HRP30036?
You can download the HRP30036 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HRP30036?
MEAN WELL
