MEAN WELL IDLC65A700 LED Driver
The IDLC-65A700 is a high-efficiency 65W LED driver designed for indoor lighting, floodlights, and LED panels. Operating from 180~295VAC, it offers constant current output with flicker-free performance, ensuring stable illumination. Features include 2-in-1 dimming options, auxiliary power output, and DALI control technology, making it flexible for various lighting applications. Its compact plastic housing supports wide operating temperature range from -20°C to +85°C with a fanless design. Certified with UL8750, ENEC, and CE standards, it guarantees safety and reliability for professional lighting setups.
MEAN WELL IDLC65A700 LED Driver Specifications:
- Rated Power: 65W
- Rated Current: 700mA
- Output Voltage Range: 69~93V
- Open Circuit Voltage Max: 118V
- Efficiency: 89%
- Power Factor: Typical 0.95
- Input Voltage: 180~295VAC
- Frequency Range: 47~63Hz
- Working Temperature: -20°C to +85°C
- Dimensions: 130*75*25mm (L*W*H)
- Protection: Short circuit, overcurrent
- Inrush Current: 30A @ 230VAC
- Leakage Current: <0.75mA/277VAC
- Standby Power: <0.5W
- Certifications: UL8750, ENEC, CE, EAC
Buy the Buy MEAN WELL IDLC-65A700 LED Driver Part Number IDLC65A700 Online
Enhance your lighting setup with the MEAN WELL IDLC-65A700 LED driver, delivering 65W of reliable, flicker-free constant current power suitable for indoor applications. It supports a wide input voltage range and offers advanced dimming options, including 0-10VDC and PWM, along with DALI control for intelligent lighting management. With a compact form factor and high efficiency of up to 89%, it ensures energy savings and minimal heat generation. Perfect for LED panels, floodlights, and indoor lighting systems requiring robust performance and compliance with international safety standards.
Get MEAN WELL IDLC-65A700 today—built for precision, high efficiency, and long-lasting durability in LED lighting projects.
