MEAN WELL IRM0224 Miniature Power Supply
The IRM-02 series is a compact, 2W encapsulated AC-DC power supply module designed for industrial and electronic applications. Its fully potted phenolic case ensures heat dissipation, dust, and moisture resistance, meeting anti-vibration standards up to 5G. It supports a universal input range of 85–305VAC with high efficiency up to 77% and low no-load power consumption below 0.075W, complying with global low power regulations. Features include overload, overvoltage protections, and EMI filtering, making it suitable for factory automation, handheld devices, and industrial equipment. SMD and PCB mounting options are available.
MEAN WELL IRM0224 Miniature Power Supply Specifications:
- Output Power: 2W
- Input Voltage Range: 85–305VAC
- Output Voltages: 3.3V, 5V, 9V, 12V, 15V, 24V
- Rated Currents: 600mA, 400mA, 222mA, 167mA, 133mA, 83mA
- Ripple & Noise: Max 200mVp-p
- Voltage Tolerance: ±2.5% to ±25%
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- Efficiency: Up to 77%
- No-load Power Consumption: < 0.075W
- Operating Temperature: -30°C to +85°C
- Enclosure: Phenolic case, fully potted silicone
- Size: 33.7mm x 22.2mm x 15mm (PCB mounting), 46mm (SMD style)
- Protection: Short circuit, Overload, Over voltage
- Vibration Resistance: Up to 5G
- Certifications: UL60950-1, TUV EN60950-1, EN55022 Class B
- Isolation Voltage: 3KVAC
- EMC Compliance: EN55022 Class B, EN61000-3-2, -3
- MTBF: 1960Khrs min (25°C)
Buy the Buy MEAN WELL IRM-02-24 Part Number IRM0224 Online
Purchase the MEAN WELL IRM-02-24 power supply today online for dependable, compact power conversion ideal for industrial and electronic applications. Its 2W output, universal input voltage, high efficiency, and low no-load power consumption make it perfect for factory automation, handheld electronic devices, and machinery. The robust phenolic case, vibration resistance up to 5G, and compliance with international safety and EMI standards ensure reliability and safety. Easy integration through PCB or SMD mounting makes it suitable for diverse industrial environments.
Get MEAN WELL IRM0224 today—compact, reliable power supply, ideal for industrial automation, factories, and electronic devices with built-in protections.
Frequently Asked Questions
Where can I buy MEAN WELL IRM0224?
You can click on the BUY or RFQ button to purchase IRM0224 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part IRM0224?
You can download the IRM0224 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of IRM0224?
MEAN WELL
