MEAN WELL SD200D24 Industrial Power Supply
The SD200D24 is a high-performance 200-watt single output DC-DC converter designed for industrial applications. It features a 2:1 wide input range, high efficiency (up to 86%), and comprehensive protections including short circuit, overload, overvoltage, and overtemperature. The converter provides 1500VAC isolation and excellent thermal performance with cooling by free air convection. Its rugged design meets UL60950-1 safety standards, ensuring reliable operation in demanding environments. Suitable for power supply and automation systems, it offers a compact footprint with dimensions of 215x415x50mm and a 2-year warranty for peace of mind.
MEAN WELL SD200D24 Industrial Power Supply Specifications:
- Input Voltage Range: 19-36VDC (Bi), 36-72VDC (C), 72-144VDC (D)
- Output Voltage: 24V
- Output Power: 200W
- Rated Current: 8.48A at 24V
- Ripple & Noise (max): 200mVp-p
- Efficiency (Typ): 86%
- Isolation Voltage: 1500VAC
- Protection: Short circuit, Overload, Over voltage, Over temperature
- Operating Temperature: -20°C to +60°C (derating applies)
- Dimensions: 215mm x 415mm x 50mm
- Input Voltage Tolerance: ±2%
- Line Regulation: ±0.5%
- Load Regulation: ±1%
- MTBF: 218,200 hours
- Safety Standard: UL60950-1 (for SD-200C-24), IEC60950-1, CB approval by TUV
- Vibration Resistance: 10-500Hz, 2G
- Relative Humidity: 20-90% RH non-condensing
- Storage Temperature: -40°C to +85°C
Buy the Mean Well SD200D24 – Reliable Power Supply for Industrial Applications
Secure your industrial power solutions today with the SD200D24 converter. Designed for durability and efficiency, it provides stable 24V output with high overload and short circuit protections, ensuring continuous operation. Its compact design and comprehensive safety features make it ideal for automation, manufacturing, and control systems. With a 2-year warranty, fast online purchase, and worldwide shipping options, you can trust this power supply to meet demanding industrial environments. Upgrade to reliable power today for seamless operational performance.
Buy Mean Well SD200D24 now and experience unmatched reliability and performance for your industrial power needs.
Frequently Asked Questions
Where can I buy MEAN WELL SD200D24?
You can click on the BUY or RFQ button to purchase SD200D24 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part SD200D24?
You can download the SD200D24 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of SD200D24?
MEAN WELL
