MEAN WELL MDR10024 Industrial Power Supply
The MDR-100-24 is a 96W industrial power supply designed for DIN rail mounting, offering a 24V output with a rated current of 2A. It features universal AC input, protections against short circuit, overload, overvoltage, and overtemperature, and uses ZCSIZVS technology to reduce power dissipation. Suitable for automation and industrial applications, it operates efficiently with a high power factor, has a compact dimension of 55*90*100mm, and includes a DC OK relay signal for status monitoring. This supply is ideal for robust, reliable voltage regulation in demanding environments.
MEAN WELL MDR10024 Industrial Power Supply Specifications:
- Dimensions: 55*90*100mm (W*H*D)
- Output Voltage: 24V
- Rated Current: 2A
- Rated Power: 96W
- Ripple & Noise: 450mVp-p
- Voltage Adjustment Range: 24~30V
- Input Voltage Range: 85~264VAC / 120~370VDC
- Efficiency: 87%
- Protections: Short circuit, Overload, Overvoltage, Over temperature
- Operating Temperature: -10 ~ +60°C
- Vibration Resistance: 10~500Hz, 2G
- Safety Standards: UL508, TUV EN60950-1
- Dimensions: 55*90*100mm
- Power Factor: 0.98 at full load
- Work Humidity: 20-90% RH non-condensing
Buy the Mean Well Series MDR-100 24V Power Supply: MDR10024
Purchase the Mean Well Series MDR-10024 power supply online today and enjoy dependable performance with a compact design suitable for industrial automation setups. Featuring universal AC input, protections for short circuit, overload, overvoltage, and overtemperature, and high efficiency, this power supply ensures stable operation in demanding environments. Its DIN rail compatibility and DC OK relay contact provide easy integration and status monitoring. Get reliable power delivery and improve your equipment's performance with this robust and compact industrial power supply available online now.
Order your Mean Well Series MDR-10024 industrial DIN rail power supply today and ensure reliable voltage regulation for your automation projects.
Frequently Asked Questions
Where can I buy MEAN WELL MDR10024?
You can click on the BUY or RFQ button to purchase MDR10024 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part MDR10024?
You can download the MDR10024 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of MDR10024?
MEAN WELL
