MEAN WELL MFM0524 Medical Power Supply
The MFM-05-24 is a compact, high-reliability 5W medical power supply designed for On Board applications. It features a small size of 42 x 22.3 x 20.5 mm, operates at 80~264VAC with efficiency up to 82%, and has a low no-load power consumption below 0.075W. Certified for medical safety (2 x MOPP), it includes protections such as overload, over-voltage, and over-temperature shutdown. Suitable for BF applications, it supports wide temperature and humidity ranges, making it ideal for portable medical devices, medical monitors, and exam instruments.
MEAN WELL MFM0524 Medical Power Supply Specifications:
- Model: MFM-05-24
- Output Voltage: 24V
- Rated Current: 0.23A
- Peak Current: 0.25A
- Rated Power: 5W
- Peak Load: 5.4W
- Ripple & Noise: 180mVp-p
- Voltage Tolerance: ±2.5%
- Line Regulation: 40.3%
- Load Regulation: 40.5%
- Input Voltage: 80 ~ 264VAC
- Efficiency: 82% (typical)
- Leakage Current: <80μA at 264VAC
- Isolation: 2xMOPP, 4KVAC
- Operating Temperature: -40 ~ +85°C
- Storage Temperature: -40 ~ +100°C
- Operating Humidity: 20~90% RH
- Soldering Temp.: 260°C ± 5°C for max 10 sec
- Vibration: 10~500Hz, 5G, 60 min/axis
- MTBF: >1799.5K hours
- Dimensions: 42 x 22.3 x 20.5mm
- Safety Standards: IEC60601-1, EN60601-1, UL/CSA
Buy the Mean Well MFM-05-24 – Reliable Medical Power Supply for Industrial Applications
Purchase the reliable and efficient MFM-05-24 medical power supply online today for your portable and medical equipment. This compact 5W device offers high efficiency up to 82%, UL/CSA safety certification, and protection features including overload, over-voltage, and over-temperature shutdown. Designed to operate from 80 to 264VAC, it supports wide temperature ranges from -40°C to +85°C, making it ideal for medical monitors, portable devices, and portable instruments. Ensure your medical solutions run safely and reliably with this certified power supply, easily ordered online for quick deployment.
Order your Mean Well Series MFM-05-24 medical power supply today and ensure your portable medical devices operate reliably with high efficiency and safety.
Frequently Asked Questions
Where can I buy MEAN WELL MFM0524?
You can click on the BUY or RFQ button to purchase MFM0524 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part MFM0524?
You can download the MFM0524 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of MFM0524?
MEAN WELL
