MEAN WELL MPM0512 Medical Power Supply Module
The MPM-05 series is a compact, high-reliability medical power supply module offering 5W of power, suitable for BF applications, with low power consumption and high efficiency. Designed to meet IEC/EN60601-1 and ANSI/AAMI ES60601-1 standards, it features a small size of 45.7 x 25.4 x 21.5 mm, operates from 80-264VAC, and provides multiple output voltages including 3.3V, 5V, 12V, 16V, and 24V. Its robust design includes features like over-voltage, over-temperature protections, and high EMC performance, making it ideal for portable medical devices, monitoring systems, and safety-critical equipment.
MEAN WELL MPM0512 Medical Power Supply Module Specifications:
- Dimensions: 45.7 x 25.4 x 21.5 mm
- Operating Voltage: 80-264VAC
- Output Voltages: 3.3V, 5V, 12V, 16V, 24V
- Rated Power: 5W
- Efficiency: Up to 82%
- Leakage Current: <80μA at 264VAC
- Protection: Over-voltage, over-temperature, short circuit, overload
- Isolation Level: 2xMOPP, 4KVAC
- Temperature Range: -40°C to +85°C
- Vibration: 5G for 60 min along X,Y,Z axes
- Dimensions: 45.7mm length, 25.4mm width, 21.5mm height
- Humidity: 20-90% RH non-condensing
- MTBF: 1799.5K hours
- Compliance: IEC60601-1, EN60601-1, UL, CSA
- No minimum load required, typical lifetime >48,000 hours
Buy the Buy Medical Power Module Series MPM-05 Part Number MPM0512 Online
Experience the high reliability and safety of the MPM-05 series medical power supply. With 5W output, wide input range, and robust protections, it is ideal for BF medical devices, portable systems, and monitoring equipment. Its compact size of 45.7x25.4x21.5mm allows for easy integration into space-constrained environments. Certified to IEC/EN60601-1 standards, it offers low leakage current, high efficiency up to 82%, and excellent EMI performance. Purchase online today for a dependable power solution that ensures safety and consistent operation in medical settings.
Buy Medical Power Module MPM-05 series now and ensure reliable, low-noise power for critical medical applications.
Frequently Asked Questions
Where can I buy MEAN WELL MPM0512?
You can click on the BUY or RFQ button to purchase MPM0512 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part MPM0512?
You can download the MPM0512 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of MPM0512?
MEAN WELL
