MEAN WELL NPB24012TB Compact Power Charger
The MEAN WELL NPB-240 series is a 240W charger designed for compatibility with both flooded, gel, and AGM lead-acid, as well as lithium iron and lithium manganese batteries. This Class I power unit (with FG) is equipped with a standard IEC320-C14 AC inlet and two or three-stage charging control. The series supplies different models with output voltages ranging between 10.5VDC and 60.8VDC, satisfying the demands for various battery devices. It's suitable for applications like radio systems, electric scooters, camping cars, and heavy-duty trucks.
MEAN WELL NPB24012TB Compact Power Charger Specifications:
- Output connector: TB type
- Rated wattage: 205.2W
- Input voltage range: 90 ~ 264VAC
- Input voltage frequency: 47 ~ 63Hz
- Power factor: >0.98/115VAC, >0.95/230VAC
- Efficiency: 92%
- Adjustable output voltage range: 10.5 ~ 15.2V, 21 ~ 30.4V, 42 ~ 60.8V
- Adjustable output current range: 50% ~ 100% rated current
- Operating temperature: -30 ~ +70℃
- Storage temperature: -40 ~ +85℃
- Safety standards: UL62368-1, EN60335-1/2-29, IEC62368-1
- Protection: Short circuit, Over voltage, Over temperature, Reverse polarity
- Warranty: 3 years
